 WARNING

To avoid serious personal injury, do not attempt
to use the product until you read thoroughly and
understand completely the operator’s manual. If you
do not understand the warnings and instructions in the
operator’s manual, do not use the product. Call the
authorised service centre for assistance.

DESCRIPTION

See figure 1.

1.  Side discharge deflector
2. Primer bulb
3. Fuel cap
4. Starter grip
5. Oil cap/dipstick
6.  Height adjustment lever
7. Quick-release fastener
8. Power lever
9. Handle
10. Self-propel bail
11. Rope guide nut
12. Rear discharge door
13. Grass catcher
14. Fuel valve
15. Locking pin
16. Air filter
17. Mulching plug
18. Pins
19. Side discharge door
20. Hooks of side discharge deflector
21. Side discharge door opening
22. Spark plug boot
23. Variable throttle lever
24. Variable transmission lever
25. Cable retainer
26. Locking mechanism

ASSEMBLY

UNPACKING

The product requires assembly.

■

Carefully inspect the product to make sure no breakage
or damage occurred during shipping.

■

If any parts are damaged or missing, please call your
RYOBI service centre for assistance.

 WARNING

If any parts are damaged or missing, do not operate the
product until the parts are replaced. Using a product
with damaged or missing parts could result in serious
personal injury.

 WARNING

Do not attempt to modify the product or create
accessories not recommended for use with the product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible
serious personal injury.

 WARNING

The product safety systems or features shall not be
tampered with or disabled.

 WARNING

Never attach or adjust any accessory while the product
is running. Failure to stop the engine may cause
serious personal injury.

 WARNING

To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark
plug wire from the spark plug when assembling parts.

 WARNING

Never operate the mower without the proper safety
devices in place and working. Never operate the mower
with damaged safety devices. Operation of this product
with damaged or missing parts could result in serious
personal injury.

INSTALLATION OF THE HANDLE

See figure 2.

1.  Place handles in correct operating position. Ensure the

locking pin on the lower handle is inserted in the hole
of the bracket.

2.  Place the quick-release fasteners and tighten the quick-

release knobs to secure.

NOTE:

 Do not pinch the cable.

3.  Place the cable retainer on the handle.
4.  Place the cables in the cable retainer.
5.  Place starter rope in guide on handle.
6.  Install grass catcher or mulching plug.

INSTALLING THE MULCHING PLUG (FOR MULCHING
OPERATION)

See figure 3.

NOTE:

 When using the mulching plug, do not install the

grass catcher.
1.  Lift and hold up the rear discharge door.
2.  Grasp the mulching plug by its handle and insert it at a

slight angle, as shown.

3.  Push the mulching plug securely into place.
