Stopping the engine

1.  Release the power lever and allow the engine to come

to a complete stop.

2.  Close the fuel valve.

PROPELLING THE PRODUCT

See figure 6.

■

To self-propel: Hold down the power lever while slowly

pulling the self-propel bail towards the handle. Release

the self-propel bail to stop the wheel drive.

■

To manually propel: Hold down the power lever. Do not

engage the self-propel bail.

NOTE:

 The product will start to run when the self-propel

bail is engaged.

SETTING BLADE HEIGHT

See figure 7.

When shipped, the wheels on the mower are set to a low-

cutting  position.  Before  using  the  mower  for  the  first  time,

adjust the cutting position to the height best suited for your

lawn. The average lawn should be between 38 mm to 50

mm during cool months and between 50 mm and 76 mm

during hot months.

To set the blade height:

■

Stop the product and wait for the blade to come to a

complete stop.

■

To raise the blade height, grasp the height adjustment

lever and move it toward the back of the mower.

■

To lower the blade height, grasp the height adjustment

lever and move it toward the front of the mower.

SETTING HANDLE HEIGHT AND ANGLE

See figure 8.

The height of the handle can be easily adjusted for operator

preference.

To adjust the handle height:

■

Remove the quick-release knob.

■

Slide out the quick-release lever and adjust the height

to the other opening.

■

Reinstall the quick-release fastener. Tighten the quick-

release knob.

■

Repeat on the other side of the handle.

To adjust the handle angle:

■

Release the lower quick-release fasteners.

■

Change the handle angle according to preference.

Ensure the locking pin on the lower handle is inserted

in the hole of the bracket.

NOTE:

 The product has a 3-point handle angle

adjustment setting.

■

Reinstall the lower quick-release fasteners.

MOWING TIPS

■

Make sure the lawn mower mowing area is clear of

stones, sticks, wires, and other objects that could

damage the lawn mower blades or engine. Such

objects could be accidentally thrown by the mower in

any direction and cause serious personal injury to the

operator and others.

■

For best performance, always cut off one-third or less of

the total height of the grass.

■

When cutting long grass, reduce walking speed to allow

for more effective cutting and a proper discharge of the

clippings.

■

Do not cut wet grass, it will stick to the underside of the

deck and prevent proper bagging or mulching of grass

clippings.

■

New or thick grass may require a higher cutting height

and a narrower cutting path.

■

Clean the underside of the mower deck after each use

to remove grass clippings, leaves, dirt, and any other

accumulated debris. Refer to “Cleaning the underside

of the mower deck” section.

SLOPE OPERATION TIPS

See figure 10.

■

Slopes are a major factor related to slip-and-fall

accidents that can result in severe injury. Operation on

slopes requires extra caution. If you feel uneasy on a

slope, do not mow it. For your safety, do not attempt to

mow slopes greater than 15 degrees. Do not use the

drive wheels when mowing on slopes.

■

Mow across the face of slopes, never up and down.

Exercise extreme caution when changing direction on

slopes.

■

Watch for holes, ruts, rocks, hidden objects, or bumps

which can cause you to slip or trip. Tall grass can hide

obstacles. Remove all objects such as rocks, tree limbs,

etc., which could be tripped over or thrown by the blade.

■

Always be sure of your footing. A slip and a fall can

cause serious personal injury. If you feel you are losing

your balance, immediately release the power lever.

■

Do not mow near drop-offs, ditches, or embankments;

you could lose your footing or balance.

EMPTYING THE GRASS CATCHER

See figure 11.

1.  Stop the product and wait for the blade to come to a

complete stop.

2.  Lift the rear discharge door.

3.  Grasp grass catcher by its handle and lift to remove

from the product.

4.  Empty grass clippings.

5.  Lift the rear discharge door and reinstall the grass

catcher.
