ASSEMBLY

UNPACKING

The product requires assembly.

■

Carefully inspect the product to make sure no breakage

or damage occurred during shipping.

■

If any parts are damaged or missing, please call your

Ryobi service centre for assistance.

 WARNING

If any parts are damaged or missing, do not operate the

product until the parts are replaced. Using a product

with damaged or missing parts could result in serious

personal injury.

 WARNING

Do not attempt to modify the product or create

accessories not recommended for use with the product.

Any such alteration or modification is misuse and could

result in a hazardous condition leading to possible

serious personal injury.

 WARNING

The product safety systems or features shall not be

tampered with or disabled.

 WARNING

Never attach or adjust any accessory while the product

is running. Failure to stop the engine may cause

serious personal injury.

 WARNING

To prevent accidental starting that could cause serious

personal injury, always disconnect the engine spark

plug wire from the spark plug when assembling parts.

 WARNING

Never operate the mower without the proper safety

devices in place and working. Never operate the mower

with damaged safety devices. Operation of this product

with damaged or missing parts could result in serious

personal injury.

INSTALLATION

See figure 2.

1.  Place handles in correct operating position. Ensure the

locking pin on the lower handle is inserted in the hole

of the bracket.

2.  Place the quick-release fasteners and tighten the quick-

release knobs to secure.

NOTE:

 Do not pinch the cable.

3.  Place the cable retainer on the handle.

4.  Place the cables in the cable retainer.

5.  Place starter rope in guide on handle.

6.  Install grass catcher or mulching plug.

INSTALLING THE MULCHING PLUG (FOR MULCHING

OPERATION)

See figure 3.

NOTE:

 When using the mulching plug, do not install the

grass catcher.
1.  Lift and hold up the rear discharge door.

2.  Grasp the mulching plug by its handle and insert it at a

slight angle, as shown.

3.  Push the mulching plug securely into place.

4.  Lower the rear discharge door.

ASSEMBLING THE GRASS CATCHER

1.  Slide plastic clips over the metal frame.

2.  Snap the rest of the grass catcher parts into place.

INSTALLING THE GRASS CATCHER (FOR REAR BAG-

GING OPERATION)

See figure 4.

NOTE:

When using the grass catcher, do not install either

the  side  discharge  deflector  or  the  mulching  plug.  Also,

ensure side discharge door is closed securely.
1.  Lift the rear discharge door.

2.  Lift the grass catcher by its handle and place under the

rear door, so that the hooks on the grass catcher frame

are seated on the hinge rod of the rear door.

3.  Release the rear door. When installed correctly, the

hooks on the grass catcher will rest securely on the

hinge rod of the rear door.

4.  Ensure the rear door is fully engaged on the grass

catcher. Make sure that there is no gap between the

rear door and the grass catcher.

INSTALLING SIDE DISCHARGE DEFLECTOR (FOR

SIDE DISCHARGE OPERATION)

See figure 9.

NOTE:

  When  using  the  side  discharge  deflector,  do  not

install the grass catcher. The mulching plug should remain

installed.

NOTE:

  When  the  side  discharge  deflector  is  not  used,

ensure that the side discharge door is in lock position.
1.  Push down the locking mechanism by one hand and lift

the side discharge door with another hand.

2.  Align  the  hooks  on  the  deflector  with  the  hinge  rod  on

the underside of the door.

3.  Lower the deflector until the hooks are secured on the

mulch door hinge rod.

4.  Release the deflector and side discharge door.

NOTE:

 After each use, clean and inspect the locking

mechanism if it is still functioning properly.
