Caution!

Residual risks

Even if you use this electric power tool in

accordance with instructions, certain resi-

dual risks cannot be rules out. The following

hazards may arise in connection with the

equipment’s construction and layout:

1.   Damage to hearing if no suitable ear protec-

tion is used.

2.   Health damage caused by hand-arm vib-

rations if the equipment is used over a pro-

longed period or is not properly guided and

maintained.

5. Before starting the equipment

5.1 Assembling the components

Some parts of the equipment come disassem-

bled. For quick and easy assembly, read and

follow the instructions below.

Note! You will need the following additional tools

(not supplied) for assembly, and also for mainte-

nance work:

•

One flat oil drip tray (for changing the oil)

•

One 1 liter measuring jug (oil/petrol resistant)

•

One petrol can

•

One funnel (suitable for the tank’s petrol filler

neck)

•

Household wipes (to wipe up oil/petrol resi-

due; dispose of these at a filling station)

•

One petrol suction pump (plastic, available

from DIY stores)

•

One oil can with hand pump (available from

DIY stores)

•

Engine oil

Assembly

1.  Fit the lower and upper push bar (Item. 3) as

shown in Fig. 3a-3b. For fastening choose

one of the holes to suit the required height of

the push bar.

Important! The identical height must be set

on both sides.

2.  Insert the grip of the starter cable (Item 9) into

the hook provided for that purpose as shown

in Fig. 3c.

3.  Fasten the actuator cables to the push bar

with the supplied cable clips (Item 10) as

shown in Fig. 3d.

4.  Lift the ejector flap (Item 5a) with one hand

and hook in the grass bag (Item 4a) as shown

in Fig. 4a.

5.2. Adjusting the cutting height

Warning! Adjust the cutting height only when

the engine has been switched off.

•

The cutting height is centrally adjusted with

the cutting height adjustor lever (Fig. 7/Item

8). Different cutting heights can be selected.

•

Actuate the adjustor lever and pull it to the

required position. Let the lever click into po-

sition.

6. Operation

Note!

The engine comes without oil and petrol.

Therefore, be sure to add oil and petrol befo-

re starting the engine.

The enclosed engine manual from Briggs &

Stratton provides maintenance information

and maintenance interval information on the

engine.

Warning: Never use more than one safety petrol

can. Do not smoke when refueling. Switch off the

engine before refueling and allow the engine to

cool down for a few minutes.

Ensure that the ignition cable is connected to the

spark plug.

Carrying out a safety test on the engine start/

stop lever

The lawn mower comes equipped with an engi-

ne start/stop lever (Fig. 5a/Item 1a) in order to

prevent it from starting up unintentionally and to

ensure that the engine and blade stop quickly in

case of danger. The lever must be actuated (Fig.

5b) before the lawn mower is started. When the

engine start/stop lever is released, it must return

to its initial position (Fig. 5a).

Before you start mowing, you should run through

this process several times in order to ensure that

the lever and actuator cables are working pro-

perly.

Repeat the test several times after the engine

has started up. When the engine start/stop lever

is released, the engine must stop within a few se-

conds. If not, contact Customer Service.
