8 ENGLISH

Low battery voltage:

The remaining battery capacity is too low and the tool

will not operate. If you turn the tool on, the motor runs

again but stops soon. In this situation, remove and

recharge the battery.

Indicating the remaining battery

capacity

Only for battery cartridges with the indicator

►

Fig.2:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indi-

cate the remaining battery capacity. The indicator lamps

light up for a few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

75% to 100%

50% to 75%

25% to 50%

0% to 25%

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Switch action

►

Fig.3:

1.

 Switch lever

CAUTION:

Before installing the battery car-

tridge into the tool, always check to see that the

switch lever actuates properly and returns to the

"OFF" position when released.

To start the tool, simply pull the switch lever. Tool speed

is increased by increasing pressure on the switch lever.

Release the switch lever to stop.

Lighting up the front lamp

CAUTION:

Do not look in the light or see the

source of light directly.

►

Fig.4:

1.

 Switch lever

2.

 Lamp

Pull the switch lever to light up the lamp. The lamp

keeps on lighting while the switch lever is being pulled.

The light automatically goes out approximately 10 sec-

onds after the switch lever is released.

NOTE:

 Use a dry cloth to wipe the dirt off the lens of

the lamp. Be careful not to scratch the lens of lamp, or

it may lower the illumination.

Reversing switch action

►

Fig.5:

1.

 Reversing switch lever

CAUTION:

Always check the direction of

rotation before operation.

CAUTION:

Use the reversing switch only after

the tool comes to a complete stop.

 Changing the

direction of rotation before the tool stops may dam-

age the tool.

CAUTION:

When not operating the tool,

always set the reversing switch lever to the neu-

tral position.

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the

A side for clockwise rotation or from the B side for coun-

terclockwise rotation.

When the reversing switch lever is in the neutral posi-

tion, the switch lever cannot be pulled.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing driver bit

For tool with sleeve to retain the bit

Use only driver bit/socket bit that has inserting portion

shown in the figure. Do not use any other driver bit/

socket bit.

►

Fig.6:

(1)

 12 mm

(2)

 9 mm

To install the driver bit, pull the sleeve in the direction of

the arrow and insert the driver bit into the sleeve as far

as it will go.

Then release the sleeve to secure the driver bit.

►

Fig.7:

1.

 Driver bit

2.

 Sleeve

For tool without sleeve to retain

the bit

Use only driver bit/socket bit that has inserting portion

shown in the figure. Do not use any other driver bit/

socket bit.

►

Fig.8:

(1)

 8 mm

Use insert bits shown in the figure. To install the bit, just

insert it into the spindle.

►

Fig.9:

1.

 Insert bit

2.

 Spindle

NOTE:

 If the driver bit is not inserted deep enough

into the sleeve, the sleeve will not return to its original

position and the driver bit will not be secured. In this

case, try re-inserting the bit according to the instruc-

tions above.
