7

GB

Router

INTENDED USE

The tool is intended to route grooves, edges, pro

fi

 les and elon-

gated holes in wood, plastic and light building materials as well
as to copy-route

TECHNICAL SPECIFICATIONS

 1

PRODUCT ELEMENTS

 2

1

   On/off switch

2

   Handle

3

   Router base

4

   Locking bolt for parallel guide

5

   Opening for parallel guide

6

 Collet

nut

7

 Spindle

lock

8

 Revolver-depth

stop

9

  Locking bolt depth stop

10

 Depth stop

11

 Clamping lever

12

  Scale cutting depth

13

  Adjusting wheel electronic speed control

14

  Height adjusting button

SAFETY

WARNING!  Read all instructions. Failure to follow all instructions
listed below may result in electric shock,

fi

 re and/or serious in-

jury.

GENERAL

•  This tool should not be used by people under the age of 16

years

•  Always disconnect plug from power source before making any

adjustment or changing any accessory

ACCESSORIES

•  SBM Group can assure

fl

 awless functioning of the tool only

when original accessories are used

•  Use only accessories with an allowable speed matching at

least the highest no-load speed of the tool

•  Do not use damaged or deformed router bits
•  Only use sharp router bits
•  Protect accessories from impact, shock and grease
•  Only use high speed steel (HSS) or carbide-tipped (CT) router

bits with this tool

BEFORE USE

•  Avoid damage that can be caused by screws, nails and other

elements in your workpiece; remove them before you start
working

•  Always check that the supply voltage is the same as the volt-

age indicated on the nameplate of the tool (tools with a rating
of 230V or 240V can also be connected to a 220V supply)

•  Do not work with materials containing asbestos
•  Clamp the workpiece in case it does not remain stationary

from its own weight

•  Do not clamp the tool in a vice
•  Use completely unrolled and safe extension cords with a ca-

pacity of 16 Amps (UK 13 Amps)

•  The noise level when working can exceed 85 dB(A); wear ear

protection

•  Wear a dust protection mask when working with materials

which produce dust that is detrimental to health; inform your-
self beforehand about the materials to be worked on

•  Be sure tool is switched off when plugging in

DURING USE

•  Always keep the cord away from moving parts of the tool; di-

rect the cord to the rear, away from the tool

•  Never use tool when cord or base-plate (=protective guard) is

damaged; have it replaced by a quali

fi

 ed person

• Keep

hands

and

fi

 ngers away from router bit when tool is

switched on

•  Never exceed maximum cutting depth of router bit while cut-

ting

•  In case of electrical or mechanical malfunction, immediately

switch off the tool and disconnect the plug

•  In case the router bit is blocked, resulting in jerking forces on

the tool, immediately switch off the tool

•  In case of current interruption or when the plug is accidentally

pulled out, immediately switch off the tool in order to prevent
uncontrolled restarting

•  Do not apply so much pressure on the tool that it comes to a

standstill

AFTER USE

• After

fi

 nishing the work, lift lever, guide the tool back into the

upper starting position, and switch off the tool

WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):

•  Do not connect the blue (= neutral) or brown (= live) wire in the

cord of this tool to the earth terminal of the plug

•  If for any reason the old plug is cut off the cord of this tool, it

must be disposed of safely and not left unattended

 3

  Mounting adapter plate (for copying with a template)

 4

   Mounting rip fence

 5

   Circular guide

 6

   Mounting/removing router bits

 7

   Speed control

 8

   Changing collet

 9

   Mounting/removing of vacuum cleaner adapter

 10

  Operating the tool

Your machine is double insulated in accordance with
EN 50144; therefore no earthwire is required.

MAINTENANCE

Make sure that the machine is not live when carrying
out maintenance work on the motor.

Regularly clean the machine housing with a soft cloth, prefer-

ably after each use. Keep the ventilation slots free from dust and
dirt.If the dirt does not come off use a soft cloth moistened with
soapy water. Never use solvents such as petrol, alcohol, ammo-
nia water, etc. These solvents may damage the plastic parts.

The machine requires no additional lubrication.
Should a fault occur, e.g. after wear of a part, please contact

your local SBM Group dealer.

ENVIRONMENT

In order to prevent the machine from damage during transport,

it is delivered in a sturdy packaging. Most of the packaging ma-
terials can be recycled. Take these materials to the appropriate
recycling locations. Take your unwanted machines to your local
SBM Group dealer. Here they will be disposed of in an environ-
mentally safe way.
