GB

10

I

Viewfinder

• When using the viewfinder, slide

down the Viewfinder pop-up
switch, then pull the eyepiece out
from the viewfinder until it
clicks.

• When you look into the

viewfinder, the viewfinder mode
is activated, and when you take
your face away from the
viewfinder, the viewing mode
returns to the monitor mode.

J

Microphone

K

Viewfinder pop-up switch

L

Hook for strap

M

 (N Mark)

• Touch the mark when you

connect the camera to a
smartphone equipped with the
NFC function.

• NFC (Near Field

Communication) is an
international standard of the
short-range wireless
communication technology.

N

Control ring

O

Lens

P

Eye sensor

Q

(Flash pop-up) switch

R

Monitor

• You can adjust the monitor to an

easily viewable angle and shoot
from any position.

S

Light sensor

T

For shooting: Fn (Function)
button
For viewing:

 (Send to

Smartphone) button

U

MOVIE (Movie) button

V

Multi/Micro USB Terminal

• Supports Micro USB compatible

device.

W

HDMI micro jack

X

MENU button

Y

Wi-Fi sensor (built-in)

Z

Control wheel

wj

 (Playback) button

wk

C

/

 (Custom/Delete) button

wl

Battery insertion slot

e;

Battery eject lever

ea

Tripod socket hole

• Use a tripod with a screw less

than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.

es

Access lamp

ed

Memory card slot

ef

Battery/Memory card cover

eg

Speaker
