Cordless Chain Saw

EN

18

strike any utility line or cause any property
damage. If the tree does make contact with
any utility line, the company should be
notified immediately.
The chain saw operator should keep on the
uphill side of the terrain as the tree is likely to
roll or slide downhill after it is felled.

 An escape path should be planned and

cleared as necessary before cuts are started.
The escape path should extend back and
diagonally to the rear of the expected line of
fall.

 Before felling is started, consider the

natural lean of the tree, the location of larger
branches and the wind direction to judge
which way the tree will fall.
Remove dirt, stones, loose bark, nails staples,
and wire from the tree.

Notching undercut:

 Make the notch (x-w)

1/3 the diameter of the tree, perpendicular
to the direction of falls as make the lower
horizontal notching cut first. This will help to
avoid pinching either the saw chain or the
guide bar when the second notch is being
made.

Felling back cut:

 Make the felling back cut

(Y) at least 50 mm higher than the horizontal
notching cut. Keep the felling back cut parallel
to the horizontal notching cut. Make the felling
back cut so enough wood is left to act as a
hinge. The hinge wood keeps the tree from
twisting and falling in the wrong direction. Do
not cut through the hinge.
As the felling gets close to the hinge the tree
should begin to fall. If there is any chance that the
tree may not fall in desired direction or it may rock
back and bind the saw chain, stop cutting before
the felling back cut is complete and use wedges
of wood, plastic, or aluminum to open the cut and
drop the tree along the desired line of fall.
When the tree begins to fall remove the chain saw
from the cutting, stop the motor, put the chain saw
down, and then use the retreat path planned. Be
alert for overhead limbs falling and watch your
footing.
To complete the felling operation, drive a wedge
(Z) into the horizontal cut.
Beware of falling branches when the tree starts to
move.

Limbing a tree (See Fig. Q)

Limbing is removing the branches from a fallen
tree. When limbing leave larger lower limbs
to support the log off the ground. Remove the
small limbs in one cut as illustrated. Branches
under tension should be cut from the bottom
up to avoid binding the chain saw.

Bucking a log (See Fig. R)

Bucking is cutting a log into lengths. It is
important to make sure your footing is firm
and your weight is evenly distributed on both
feet. When possible, the log should be raised
and supported by the use of limbs, logs or
chocks. Follow the simple directions for easy
cutting.
When the log is supported along its entire as
illustrated, it is cut from the top (overbuck).
When the log is supported on one end,
as illustrated, cut 1/3 the diameter from
the underside (underbuck). Then make the
finished cut by overbucking to meet the first
cut. (See Fig. S)
When the log is supported on both ends, as
illustrated, cut 1/3 the diameter from the top
(overbuck). Then make the finished cut by
underbucking the lower 2/3 to meet the first
cut. (See Fig. T)

WARNING: (See Fig. U)

•   If on slope, make sure log will not

roll down hill. Secure log by using

wooden stakes. Drive wooden stakes

into ground on downhill side of log.

Stand on uphill side of log while

cutting. Log may roll after cutting.

•   Never try cutting through two logs

at same time. This could increase the

risk of kickback.

•   While cutting log, never hold log with

your hand, leg, or foot.

•   While cutting log, never allow another

person to hold log.

•   Turn off and remove the battery pack

from the saw before moving from one

place to another.
