Cordless Chain Saw

EN

15

TENSIONING CHAIN

New saw chains will stretch. Check chain
tension frequently when first used and tighten
when Chain becomes loose around the Guide
Bar (7).

WARNING:

Remove the battery

from the tool before adjusting saw

chain tension.

WARNING: Cutting edges on chain

are sharp. Use protective gloves

when handling chain.

WARNING: Maintain proper chain

tension always. A loose chain will

increase the risk of kickback. A loose

chain may jump out of guide bar groove.

This may injure operator and damage

chain. A loose chain will cause chain,

bar, and sprocket to wear rapidly.

1.   Place the chain saw on any suitable flat

surface.

2.  Turn the Chain Tensioning Knob (10)

clockwise until it is hand tight. The tension
is automatically set while the Chain
Tensioning Knob is being tightened.

  The ratchet mechanism (a) prevents the

chain tension from loosening. (See Fig. F1)

3.  Double check the tension set by the

automatic  Chain Tensioning  Knob. The
correct chain tension is reached when the
Chain (8) can be raised approx. 3-6mm
from the Guide Bar (7) in the center (the
chain links should just remain in the bar
track). This should be done by using one
hand to raise the chain against the weight
of the machine. (See Fig. F2)

  Use a screwdriver to move chain around

Guide Bar to ensure kinks do not exist. The
chain should rotate freely. (See Fig.  F3 )

4.  When the chain looses, unscrew the Chain

Tensioning Knob absolutely and then
Screw on the cover plate with the locking
knob tightly again.

LUBRICATION

IMPORTANT: He chain saw is

not supplied filled with oil. It is

essential to fill with oil before use. Never

operate the chain saw without chain

oil or at an empty oil tank level, as this

will result in extensive damage to the

product.

NOTE:

 Chain life and cutting capacity depend

on optimum lubrication.  Therefore, the chain
is automatically oiled during operation.

Filling oil tank:

1.   Set chain saw on any suitable surface with

Oil Filler Cap (4) facing upward.

2.  Clean area around the Oil Filler Cap with

cloth unscrew cap.

3.  Add bar and chain oil until reservoir is full.

ISO VG32 Bar and chain oil of any brand
can be used.

4.  Avoid dirt or debris entering oil tank, refit

the Oil Filler Cap and tighten.

IMPORTANT: To allow venting of

the oil reservoir, small breather

channels are provided between the oil

filler cap and the strainer, to prevent

leakage ensure machine is left in a

horizontal position (Oil Filler Cap (4)

uppermost) when not in use.

It is important to use only the

recommended oil to avoid damage to the

chain saw. Never use recycled/old oil.

Use of non approved oil will invalidate

the warranty.

CHECKING  THE AUTOMATIC OILER

Proper functioning of the automatic oiler can
be checked by running the chain saw and
pointing the tip of the Guide Bar (7) towards a
piece of cardboard or paper on the ground.
If an increasing oil pattern develops on the
cardboard, the automatic oiler is operating
fine. If there is no oil pattern, despite a full
oil reservoir, contact WORX customer service
agent or WORX approved service agent.

CAUTION:

 Do not touch the ground

with the chain. Ensure safety clearance

of 30cm.

OPERATION

1. BEFORE USING YOUR CORDLESS

TOOL

ATTENTION: The charger and

battery pack are specially designed

to work together so do not attempt to

use any other devices. Never insert or
