2

Thank you for purchasing a MAKITA product!

Congratulations on choosing a MAKITA chain saw! We are
con

Þ

 dent that you will be satis

Þ

 ed with this modern piece of

equipment. The EA3500S-EA3503S are very handy and robust
chain saws with a new Design.

The automatic chain lubrication with variable-

ß

 ow oil pump

and maintenance-free electronic ignition ensure trouble-free
operation, while the hand-saving anti-vibration system and
ergonomic grips and controls make work easier, safer, and
less tiring for the user.

The Featherlight-Start system lets you start the saw effortlessly
with a spring-loaded starting assist.

For some countries the saw is also equipped with a catalytic
converter. This reduces the amount of pollutants in the exhaust,
and meets European Guideline 2002/88/EG.

MAKITA chain saws EA3500S-EA3503S are equipped with the
latest safety features and meet all national and international
standards. These features include: hand guards on both handles,
grip throttle lever lock, chain catch, safety saw chain, and chain
brake. The chain brake can be actuated manually, and is also
inertia-actuated automatically in case of kickback.

The following industrial property rights apply:

DE 101 32 973, DE 20 2008 006 013, DE 20 2009 013 953,
DE 203 19 902, DE 203 01 182, DE 197 22 629, DE 10 2007
039 028, DE 10 2007 038 199.

In order to ensure the proper functioning and performance
of your new chain saw, and to safeguard your own per-
sonal safety, it is imperative that you read this instruction
manual thoroughly before operation. Be especially careful
to observe all safety precautions!

Failure to observe these

precautions can lead to severe injury or death!

Table of contents

Page

Delivery inventory

  .............................................................. 3

Symbols

 ............................................................................... 3

SAFETY PRECAUTIONS

General precautions  ....................................................... 4

 Protective

equipment

...................................................... 4

Fuels / Refuelling  ............................................................ 5

Putting into operation  ...................................................... 5

 Kickback

......................................................................... 6

Working behavior/Method of working ........................... 6-7

Transport and storage  ..................................................... 8

 Maintenance

................................................................... 8

 First

aid

........................................................................... 8

Technical data

  ..................................................................... 9

Packing

  ................................................................................ 9

Denomination of components

  ......................................... 10

PUTTING INTO OPERATION

Only for models with fastening nuts on the sprocket
guard

Mounting the guide bar and saw chain  .................... 11-12

Tightening the saw chain  .............................................. 12

Checking the chain tension ............................................ 13

Retightening the saw chain  ........................................... 13

Only for the QuickSet guide bar

Mounting the guide bar and saw chain  .................... 14-15

Tightening the saw chain  .............................................. 15

Checking the chain tension  ........................................... 15

Retightening the saw chain  ........................................... 15

Only for models with quick tensioner on sprocket guard


Mounting the guide bar and saw chain  .................... 16-17

Tightening the saw chain  .............................................. 17

Checking the chain tension  ........................................... 18

Retightening the saw chain  ........................................... 18

 Chain

brake

.................................................................. 18

 Fuels

........................................................................ 19-20

 Refuelling

...................................................................... 20

Checking the chain lubrication  ...................................... 21

Adjusting the chain lubrication  ...................................... 21

Starting the engine  ........................................................ 22

 Cold

start

...................................................................... 22

Warm start  .................................................................... 22

Stopping the engine  ...................................................... 22

Checking the chain brake  ............................................. 23

Adjusting the carburetor

  .................................................. 24

MAINTENANCE

Sharpening the saw chain  ....................................... 25-26

Cleaning the inside of the sprocket guard  .................... 27

Cleaning the guide bar  .................................................. 27

Replacing the saw chain  ............................................... 28

Cleaning the air

Þ

 lter  ..................................................... 29

Replacing the spark plug  .............................................. 30

Checking the ignition spark  ........................................... 30

Checking the muf

ß

 er screws  ......................................... 30

Replacing the starter cable/Replacing the return spring

cassette/Replacing the Featherlight -Start spring  ......... 31

Mounting the fan housing  ............................................. 31

Cleaning the air

Þ

 lter compartment/fan compartment  ... 32

Cleaning the cylinder

Þ

 ns  .............................................. 32

Replacing the suction head  .......................................... 32

Instructions for periodic maintenance  ........................... 33

Service, spare parts and guarantee

  ................................ 34

Trouble shooting

  .............................................................. 35

Extract from spare parts list

  ....................................... 36-37

Accessories  ............................................................. 36-37

EU conformity declaration

  ............................................... 38
