16
6
5
1
2
4
3
9
7
8
Mounting the guide bar and saw chain
Place the saw on a stable surface and perform the following
work steps in order to install the guide bar and saw chain:
Release the chain brake by pulling the hand guard (
1
) in direc-
tion of arrow.
Fold up the sprocket guard quick tensioner (
2
) (see also the
illustration on tensioning the saw chain).
Push the sprocket guard quick tensioner in forcefully against
the spring tension and slowly turn
counter-clockwise
, until
you feel it engage. Keep pushing, and turn as far as possible
counter-clockwise.
Release the sprocket guard quick tensioner again and turn
clockwise
to bring it back to its original position. Repeat this
procedure until the sprocket guard (
4
) is unscrewed.
Remove the sprocket guard (
4
).
Lift the chain (
8
) over the sprocket (
7
).
CAUTION:
Do not insert the chain
between the chain sprocket and the
disc.
Guide the chain from above about halfway into the groove (
9
)
on the guide bar.
CAUTION:
Note that the cutting edges along the top of the chain must
point in the direction of the arrow!
Put the guide bar (
5
) on and push it against the sprocket (
6
).
Only for models with quick tensioner
on sprocket guard (TLC)
CAUTION:
Before doing any work on the guide bar or chain, always
switch off the engine and pull the plug cap off the spark
plug
(see „Replacing the spark plug“)
. Always wear protec-
tive gloves!
CAUTION:
Start the chain saw only after having assembled it com-
pletely and inspected.
