6

„

Place the chain drive links into the bar

groove.

„

Position the chain so there is a loop at

the back of the bar.

„

Hold the chain in position on the

bar and place the loop around the

sprocket.

„

Fit  the  bar  flush  against  the  mounting

surface so that the bar studs are in the

long slot of the bar. Ensure that the

chain is over the sprocket. Replace the

chain cover.

„

Remove all slack from the chain by

turning the chain adjustment screw

clockwise until the chain seats snugly

against the bar with the drive links in

the bar groove.

„

Lift the tip of the guide bar up to check

for sag.

„

Release the tip of the guide bar and

turn the chain adjustment screw 1/2

turn clockwise. Repeat this process

until sag does not exist.

„

Hold the tip of the guide bar up and

tighten the chain cover lock nuts by

turning them with the wrench. The

chain is correctly tensioned when

there is no sag on the underside of the

guide bar, the chain is snug, but it can

be turned by hand without binding.

ADDING CHAIN & BAR LUBRICANT

„

Unscrew and remove the cap from the

oil tank.

„

Pour the oil into the oil tank and monitor

the oil level gauge. Ensure that no dirt

enters the oil tank while filling the oil in.

„

Put the oil cap back on and tighten it

up.

„

One full oil tank will enable you to use

the saw for 20- 40 min.

TRANSPORTING THE TOP HANDLE SAW

Before transporting the top handle saw, al-

ways  remove the battery pack from the top

handle saw and slide the chain cover over

the bar and chain. If several cuts are to be

performed with the top handle saw, the saw

must be switch off between cuts.

GUIDE BAR COVER

See figure 1

The chain cover must be clipped onto the

chain and bar as soon as the sawing work has

been completed and whenever the machine

has to be transported.

SHARPENING THE SAW CHAIN

See figure 16 - 21

When the chain penetrates into wood with

difficulty, it needs sharpening as follows:

„

Put the chain under tension.

„

Fasten the bar in a vice so that the

chain can slide.

„

Fasten  the  file  to  the  file  holder  and

place it on cutter at 35° angle.

„

File with forward strokes only until all

the worn out parts of the cutting edge

are taken away.

„

Count the number of strokes given to the

cutter  as  a  reference  and  file  away  with

the same number of strokes on all other

cutters.

„

If the depth gauge protrudes from the

template after sharpening a few times,

reset  its  level.  Use  a  flat  file.  Finally,

round off the depth gauge.

NOTE:

It is recommended to have the deep

or important sharpening carried out by a

service agent who is equipped with electric

sharpener.

GUIDE BAR MAINTENANCE

„

When you have finished working, clean

out the groove and the oil passages

with a scraping hook.

„

Periodically trim the sides of rails using

a  flat  file.  If  not  done  in  the  long  run,

the feather edges might break away

and damage the bar.

„

If one rail is higher than the other one,

it is necessary to make it even with a

flat file then smooth it with a file or fine

grain abrasive paper.
