English (original instructions)

EN

DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET

5

cut and drop the tree along the desired line

of fall. When the tree begins to fall, remove

the top handle saw from the cut, stop the

motor, put the top handle saw down, and

then use the retreat path as planned. Be

alert of overhead limbs falling and watch

your footing.

LIMBING A TREE

See figure 11

Limbing is removing the branches from a

fallen tree. When limbing, leave the larg-

er lower limbs to support the log off the

ground. Remove the small limbs in one

cut. Branches under tension should be cut

from the bottom up, to avoid binding the top

handle saw.

BUCKING A LOG

See figure 12 - 15

Bucking is cutting a log into lengths. It is

important to make sure your footing is firm

and your weight is evenly distributed on

both feet. When possible, the log should be

raised and supported by the use of limbs,

logs or chocks.

Follow the simple direction for easy cutting:

„

When the log is supported along the

entire   length, it is cut from the top

(over buck).

„

When the log is supported on one

end, cut 1/3 of the diameter from the

underside (under buck). Then make

the  finished  cut  by  over  bucking  to

meet the first cut.

„

When the log is supported on both

ends, cut 1/3 of that diameter from

the top (over buck). Then make the

finished  cut  by  under  bucking  the

lower 2/3 to meet the first cut.

„

When bucking on a slope, always

stand     on the uphill side of the log.

When cutting through, to maintain

complete control, release the cutting

pressure near the end of the cut

without relaxing your grip on the top

handle saw handles.

Do not let the chain contact the ground.

After completing the cut, wait for the saw

chain to stop before you move the top han-

dle saw. Always stop the motor before mov-

ing from tree to tree.

MAINTENANCE

WARNING

Always remove the battery pack from the

machine before checking the chain ten-

sion or making adjustments to the chain.

Wear protective gloves while touching

the chain, bar or areas around the chain.

ADJUSTING THE CHAIN TENSION

See figure 2 and figure 7

„

Loosen the chain cover lock nuts with

the supplied wrench. The chain cover

lock nuts do not have to be completely

removed in order to adjust the chain

tension.

„

Rotate the chain adjustment screw

clockwise to increase the chain

tension and rotate counterclockwise to

decrease the chain tension.

„

Once the chain is at the desired

tension, tighten the chain cover lock

nuts.

REPLACING THE BAR AND CHAIN

See Figure 3-7

„

Remove the battery from the top

handle saw.

„

Remove the chain cover lock nut

from chain cover by rotating them

counterclockwise with the wrench.

„

Remove the chain cover from the

mounting surface.

„

The bar and chain can now be removed

by lifting it away from the main body of

the saw and releasing the chain from

the sprocket.

„

Remove the old chain from the bar.

„

Lay out the new saw chain in a loop

and straighten any kinks. The cutters

should face in the direction of chain

rotation. If they face backwards, turn

the loop over.
