Do not operate the power tool stationary.

It is not de-

signed for operation with a saw table.



Do not use high speed steel (HSS) saw blades.

Such saw

blades can easily break.



Do not saw ferrous metals.

Red hot chips can ignite the

dust extraction.



When working with the machine, always hold it firmly

with both hands and provide for a secure stance.

The

power tool is guided more secure with both hands.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Always wait until the machine has come to a complete

stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.



Do not open the battery.

Danger of short-circuiting.

Protect the battery against heat, e. g., against

continuous intense sunlight, fire, water, and

moisture.

Danger of explosion.



In case of damage and improper use of the battery, va-

pours may be emitted. Ventilate the area and seek

medical help in case of complaints.

The vapours can irri-

tate the respiratory system.



Use the battery only in conjunction with your Bosch

power tool.

This measure alone protects the battery

against dangerous overload.



Use only original Bosch batteries with the voltage list-

ed on the nameplate of your power tool.

When using oth-

er batteries, e. g. imitations, reconditioned batteries or
other brands, there is danger of injury as well as property
damage through exploding batteries.

Product Description and

Specifications

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Lock-off button for On/Off switch

2

On/Off switch

3

Battery pack *

4

Blade guard

5

Lever for retracting blade guard

6

Base plate

7

Retracting blade guard

8

Parallel guide

9

Cutting mark, 0 °

10

Cutting mark, 45 °

11

Wing bolt for bevel-angle preselection

12

Wing bolt for parallel guide

13

Scale for mitre angle

14

Spindle lock button

15

Auxiliary handle (insulated gripping surface)

16

Allen key

17

Handle (insulated gripping surface)

18

Saw spindle

19

Mounting flange

20

Saw blade *

21

Clamping flange

22

Clamping bolt with washer

23

Marks on the blade guard

24

Battery unlocking button

25

Fastening screw for extraction adapter

26

Extraction adapter

27

Vacuum hose *

28

Cutting-depth scale

29

Clamping lever for cutting-depth preselection

30

Set of screw clamps *

31

Button for charge-control indicator *

32

Battery charge-control indicator *

33

Guide rail *

34

Connection piece *

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Circular Saw

GKS 18 V-LI

Article number

3 601 F6H 0..

Rated voltage

V=

18

No-load speed

min

-1

3 900

Cutting depth, max.
– for  0 °   bevel  angle
– for 45 °  bevel angle

mm
mm

51
40

Spindle lock



Base plate dimensions

mm

146 x 272

Saw blade diameter, max.

mm

165

Saw blade diameter, min.

mm

160

Blade thickness, max.

mm

1.7

Tooth thickness/setting, max.

mm

2.6

Tooth thickness/setting, min.

mm

2.0

Mounting bore

mm

20

Weight according to
EPTA-Procedure 01/2003

kg

3.9/4.1 *

* dependent of the battery pack being used
