 English |

15

Bosch Power Tools

1 609 92A 0NH | (22.5.14)

Afterwards, tighten the bottom part of the auxiliary handle

8

again by turning in clockwise direction.

The knurled surface of the depth stop

9

 must face upward.

Changing the Tool



Wear protective gloves when changing the tool.

The

drill chuck can become very hot during longer work peri-
ods.

Keyless Chuck (GSB 19-2 RE)  (see figure B)

The drill spindle is locked when the On/Off switch

6

 is not

pressed. This makes quick, convenient and easy changing of
the tool in the drill chuck possible.

Open the keyless chuck

1

 by turning in rotation direction



,

until the tool can be inserted. Insert the tool.

Firmly tighten the collar of the keyless chuck

1

 by hand in ro-

tation direction



 until the locking action (“click”) is no longer

heard. This automatically locks the chuck.

The locking is released again to remove the tool when the col-
lar is turned in the opposite direction.

Keyless Chuck (GSB 780) (see figure C)

Hold the rear sleeve

12

 of the keyless chuck

1

 tight and turn

the front sleeve

11

 in rotation direction



, until the tool can

be inserted. Insert the tool.

Hold the rear sleeve

12

 of the keyless chuck

1

 tight and firmly

turn the front sleeve

11

 in rotation direction



 by hand until

the locking action is no longer heard. This automatically locks
the drill chuck.

The locking is released again to remove the tool when the
front sleeve

11

 is turned in the opposite direction.

Key Type Drill Chuck (see figure D)

Open the key type drill chuck

14

 by turning until the tool can

be inserted. Insert the tool.

Insert the chuck key

13

 into the corresponding holes of the

key type drill chuck

14

 and clamp the tool uniformly.

Screwdriver Tools (see figure E)

When working with screwdriver bits

15

, a universal bit holder

16

 should always be used. Use only screwdriver bits that fit

the screw head.

For driving screws, always position the “Drilling/Impact Drill-
ing” selector switch

2

 to the “Drilling” symbol.

Replacing the Drill Chuck



Before any work on the machine itself, pull the mains
plug.

Removing the Drill Chuck (see figure F)

Disassemble the auxiliary handle and set the gear selector

7

to the centre position between the 1st and 2nd gear.

Insert a steel pin with a diameter of Ø 4 mm and approx.
50 mm of length into the drill hole on the spindle neck in order
to lock the drill spindle.

Clamp the short end of an Hex key

17

 into the keyless chuck

1

.

Place the machine on a stable surface (e. g. a workbench).
Hold the machine firmly and loosen the keyless chuck

1

 by

turning the Hex key

17

 in rotation direction



. Loosen a tight-

seated keyless chuck by giving the long end of the Hex key

17

a light blow. Remove the Hex key from the keyless chuck and
completely unscrew the keyless chuck.

For machines with key chuck, disassembly is carried out anal-
ogous as described above.

For machines with keyless chuck, an open-end spanner (size
19 mm) can be applied to the drill chuck instead of an Hex
key.

Mounting the Drill Chuck (see figure G)

The keyless chuck/key type drill chuck is mounted in reverse
order.



Remove the steel pin from the drill hole on the spindle
neck after mounting is completed.

The drill chuck must be tightened with a tightening
torque of approx. 50 – 55 Nm.

Dust/Chip Extraction



Dusts from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dusts can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dusts, such as oak or beech dust, are considered
as carcinogenic, especially in connection with wood-treat-
ment additives (chromate, wood preservative). Materials
containing asbestos may only be worked by specialists.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.

Observe the relevant regulations in your country for the mate-
rials to be worked.



Prevent dust accumulation at the workplace.

Dusts can

easily ignite.

Operation

Starting Operation



Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.

Reversing the rotational direction (see figure H)



Actuate the rotational direction switch 3 only when the
machine is at a standstill.

The rotational direction switch

3

 is used to reverse the rota-

tional direction of the machine. However, this is not possible
with the On/Off switch

6

 actuated.

Right rotation:

 For drilling and driving in screws, push the ro-

tational direction switch

3

 downward on the left side and at

the same time upward on the right side.

Left rotation:

 For loosening and unscrewing screws and

nuts, push the rotational direction switch

3

 upward on the left

side and at the same time downward on the right side.
