Safety Warnings for Drills



Wear ear protectors when impact drilling.

Exposure to

noise can cause hearing loss.



Use auxiliary handle(s), if supplied with the tool.

Loss

of control can cause personal injury.



Hold the tool by the insulated gripping surfaces when
performing operations where the application tool or
the screw could contact hidden wiring or its own power
cord.

Contact with a “live” wire will also make exposed

metal parts of the power tool “live” and shock the operator.



Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.



When working with the machine, always hold it firmly
with both hands and provide for a secure stance.

The

power tool is guided more secure with both hands.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Always wait until the machine has come to a complete
stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.

Products sold in GB only

: Your product is fitted with a

BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.

Products sold in AUS and NZ only

: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for impact drilling in brick, concrete
and stone as well as for drilling in wood, metal and plastic. Ma-
chines with electronic control and right/left rotation are also
suitable for screwdriving and thread-cutting.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Keyless chuck

2

“Drilling/Impact Drilling” selector switch

3

Rotational direction switch

4

Lock-on button for On/Off switch

5

Thumbwheel for speed preselection

6

On/Off switch

7

Gear selector

8

Auxiliary handle (insulated gripping surface) *

9

Depth stop *

10

Handle (insulated gripping surface)

11

Front sleeve *

12

Rear sleeve *

13

Chuck key *

14

Key type drill chuck *

15

Screwdriver bit *

16

Universal bit holder *

17

Hex key *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Impact Drill

GSB 19-2 RE

GSB 19-2 RE

GSB 780

Article number

3 601 A7B 5..

3 601 A7B 6..

3 601 A7B 1..

Rated power input

W

850

850

780

Output power

W

430

430

390

No-load speed

– 1st  gear
– 2nd  gear

min

-1

min

-1

0 – 1 000
0 – 3 000

0 – 1 000
0 – 3 000

0 – 1 000
0 – 3 000

Rated speed

– 1st  gear
– 2nd  gear

min

-1

min

-1

800

2 060

800

2 060

850

2 170

Impact frequency at no-load

min

-1

51 000

51 000

51 000

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
