FEATURES.........................................................................  1

SUPPLIED ACCESSORIES...............................................  1

ATTACHING THE NON-SKID PADS .............................  1

PLACEMENT .....................................................................  2

CONTROLS AND THEIR FUNCTIONS ..........................  2

CONNECTIONS.................................................................  3

Connecting to line output (pin jack) terminals of the
amplifier ....................................................................  3
Plug in the subwoofer to the AC outlet ............................... 3

ADJUSTING THE SUBWOOFER BEFORE USE................  3

Frequency characteristic ............................................  3

ADVANCED YAMAHA ACTIVE SERVO
TECHNOLOGY II ..............................................................  4

TROUBLESHOOTING ......................................................  4

SPECIFICATIONS .............................................................  5

• This subwoofer employs Advanced Yamaha Active

Servo Technology II, which Yamaha has developed for
the production of higher quality, super-bass sound.
(Refer to page 4 for details on Advanced Yamaha Active
Servo Technology II.) This super-bass sound adds a
more realistic, theater-in-the-home effect to your audio
system.

• This subwoofer can be easily added to your existing

audio system by connecting to either the speaker
terminals or the line output (pin jack) terminals of the
amplifier.

• This subwoofer system is equipped with a linear port

unique to Yamaha that provides smooth bass response
during playback, minimizing extraneous noise not
included in the original input signal.

After unpacking, check that the following parts are
contained.

To enjoy the high sound quality, stabilize the subwoofer
using the non-skid pads.
Attach the provided non-skid pads in the four corners of the
underside of the subwoofer to prevent the subwoofer from
moving as a result of vibration, etc.

CONTENTS

FEATURES

SUPPLIED ACCESSORIES

ATTACHING THE NON-

SKID PADS

Non-skid pads
