2
UNPACKING THE SYSTEM
Carefully unpack the system. If you suspect damage from transit,
report it immediately to your dealer and/or delivery service. Keep
the shipping carton and packing materials for future use. Open the
package and verify the following contents:
INCLUDED
1 x JBL Control X Wireless Primary speaker
1 x JBL Control X Wireless Secondary speaker
2 x AC power cord
1 x Owner’s Manual
1 x Safety sheet
TOP-PANEL CONTROLS
PRIMARY SPEAKER
1. Power
2. Bluetooth pairing (Press and Hold 2 seconds to un-pair current
Bluetooth device)
3. Transport control button (Previous track)
4. Play / Pause
5. Transport control button (Next track)
6. Volume Down
7. Volume Up
8. Battery level indication
9. Front panel LED indication
LED
information
Fixed
Quick Flash
Regular Flash
White
On / No Bluetooth
device connected
Additional speaker association
mode Volume Up and Down
(Stops when reaches Max
or Min)
System is waking up
Blue
Bluetooth device
connected
Bluetooth pairing
mode
Note:
The front LED indication times out in normal operation mode
Note:
To mute the systems simply press and hold volume up and
down simultaneously for at least 2 seconds. Simply press volume up
or volume down to un-mute the system.
SECONDARY SPEAKER
1. Power
2. Battery level indication
3. Front panel LED indication
LED
information
Fixed
Quick Flash
Regular Flash
White
On / No Bluetooth
device connected
Additional speaker association
mode Volume Up and Down
(Stops when reaches Max
or Min)
System is waking up
Blue
Bluetooth device
connected
Bluetooth pairing
mode
REAR-PANEL CONTROLS
PRIMARY SPEAKER
AC IN
AUX-IN
L/R/L+R
P
S
MODE WALL/OTHER
1
2
3
4
5 6
1. AC input connector
2. Auxiliary 3.5mm audio input
3. Primary-Secondary mode selector
4. Boundary compensation switch
a. Wall: Speaker equalization optimized for wall mounting.
b. Other: Speaker equalization optimized for other placement
conditions
5. Left / Right / Left + Right switch
a. Left: Speaker reproduces left channel information only
b. Right: Speaker reproduces right channel information only
c. Left + Right: Mono configuration speaker reproduces left and
right channels information
6. Association pin hole
1 2 3 4 5 6 7
8
9
1
2
3
