 English |

19

Bosch Power Tools

F 016 L70 481 | (10.10.08)

f

Only use or replace power supply cables for
this unit which correspond to the types indi-
cated by the manufacturer. See the operat-
ing instructions for the order no. and types.

f

Never touch the mains plug with wet hands.

f

Do not run over, crush or pull the power sup-
ply cable or extension lead, otherwise it may
be damaged. Protect the cable from heat, oil
and sharp edges.

f

The extension lead must have a cross section
in accordance with the operating instruc-
tions and be protected against splashed wa-
ter. The connection must not be in water.

f

Always wear gardening gloves when handling
or working near the sharp tines/blade.

Functional Description

Read all safety warnings and all in-
structions.

Failure to follow the

warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

Intended Use

This product is intended for domestic, lawn rak-
ing,  scarifying or verticutting of lawn.
At higher height of cut level the product is in-
tended for collection of leaves in the lawn area.

Delivery Scope

Carefully remove the machine from its packag-
ing and check if the following parts are com-
plete:
– Lawnraker (ALR 900) / Verticutter

(AVR 1100)

– Handle bottom
– Handle top
– Grassbox top
– Grassbox bottom

(packed inside grassbox top)

– 4 Bolts
– 4 Wing nuts
– 2 Cable clips
– Operating instructions

When parts are missing or damaged, please con-
tact your dealer.
When fully assembled the machine weighs ap-
proximately 9.9 – 10.4 kg. If necessary, obtain
assistance to remove from packaging.
Take care when removing from packaging or car-
rying the machine to the lawn, as the
tines/blades are sharp.

Product Features

The numbering of the components shown refers
to the representation of the machine on the
graphic pages.

1

Handle top

2

Switch lever

3

Safety button

4

Power plug **

5

Cable restraint

6

Handle bottom

7

Grassbox

8

Ventilation slots

9

Height of cut lever

10

Serial number

** country specific
Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
