 GENERAL

Carefully read the following important information regarding

installation safety and maintenance. Keep this information

booklet accessible for further consultations.

The appliance has been designed for use in the ducting

version (air exhaust to the outside – Fig.3A), filtering version

(air circulation on the inside – Fig.3B) or with external motor

(Fig.3C).

  SAFETY PRECAUTION

1.

Take care when the cooker hood is operating simultane-

ously with an open fireplace or burner that depend on the air

in the environment and are supplied by other than electrical

energy, as the cooker hood removes the air from the environ-

ment which a burner or fireplace need for combustion. The

negative pressure in the environment must not exceed 4Pa

(4x10-5 bar). Provide adequate ventilation in the environment

for a safe operation of the cooker hood.

Follow the local laws applicable for external air evacuation.

Before connecting the model to the electricity network:

- Control the data plate (positioned inside the appliance)

to ascertain that the voltage and power correspond to the

network and the socket is suitable. If in doubt ask a qualified

electrician.

- If the power supply cable is damaged, it must be replaced

with another cable or a special assembly, which may be

obtained direct from the manufacturer or from the Technical

Assistance Centre.

- This device must be connected to the supply network

through either a plug fused 3A or hardwired to a 2 fase spur

protected by 3A fuse.

2. Warning!

In certain circumstances electrical appliances may be a

danger hazard.

A) Do not check the status of the filters while the cooker

hood is operating.

B) Do not touch bulbs or adjacent areas, during or straight

after prolonged use of the lighting installation.

C) Flambè cooking is prohibited underneath the cooker

hood.

D) Avoid free flame, as it is damaging for the filters and a

fire hazard.

E) Constantly check food frying to avoid that the over-

heated oil may become a fire hazard.

F) Disconnect the electrical plug prior to any mainte -

nance.

G) This appliance is not intended for use by young children

or infirm persons without supervision.

H) Young children should be supervised to ensure they do

not play with the appliance

I)  There shall be adequate ventilation of the room when

the rangehood is used at the same time as appliances

burning gas or other fuels.

L)  There is a risk of fire if cleaning is not carried out in

accordance with the instructions.

This appliance conforms to the European Directive EC/2002/96,

Waste Electrical and Electronic Equipment (WEEE). By making

sure that this appliance is disposed of in a suitable manner, the

user is helping to prevent potential damage to the environ-

ment or to public health.

The symbol on the product or on the accompanying

paperwork indicates that the appliance should not be

treated as domestic waste, but should be delivered to

a suitable electric and electronic appliance recycling

collection point. Follow local guidelines when disposing of

waste. For more information on the treatment, re-use and

recycling of this product, please contact your local authority,

domestic waste collection service or the shop where the ap-

pliance was purchased.

  INSTALLATION INSTRUCTIONS

•  Assembly and electrical connections must be carried out

by specialised personnel.

•  Wear  protective  gloves  before  proceeding  with  the

installation.

• Electric Connection

The appliance has been manufactured as a class II, therefore

no earth cable is necessary.

The connection to the mains is carried out as follows:

BROWN =

L

 line

BLUE =

N

 neutral

If not provided, connect a plug for the electrical load indi-

cated on the description label. Where a plug is provided,

the cooker hood must be installed in order that the plug is

easily accessible.

An omnipolar switch with a minimum aperture of 3mm

between contacts, in line with the electrical load and local

standards, must be placed between the appliance and the

network in the case of direct connection to the electrical

network.

•

 The minimum distance between the support surfaces of

the cooking pots on the cooker top and the lowest part of

the cooker hood must be at least 65 cm.

 If a connection tube composed of two parts is used, the upper

part must be placed outside the lower part.

Do not connect the cooker hood exhaust to the same conduc-

tor used to circulate hot air or for evacuating fumes from other

appliances generated by other than an electrical source.

Before proceeding with the assembly operations, remove the

anti-grease filter(s) (Fig.5) so that the unit is easier to handle.

- In the case of assembly of the appliance in the suction version

prepare the hole for evacuation of the air.

•

We recommend the use of an air exhaust tube which has the

same diameter as the air exhaust outlet hole. If a pipe with

a smaller diameter is used, the efficiency of the product may

be reduced and its operation may become noisier.

•

If your appliance has been designed for use in habitations

supplied with acentralised suction device per form the

following operations:

-The switch controls opening and closure of a valve using

a thermoelectical device. By placing the switch in the

ON

position, after a minute, the valve opens rotating 90° allow-

ing suction of the stale air. By placing the switch in the

 OFF

position, the valve closes after 100 seconds.

•

 Installation

The following instruction should be followed to carry out the

correct installation of the cooker hood.

1. Mounting of the cooker hood on the lower side of the
