ENGLISH

TECHNICAL PASSPORT

Сooker hood

8.5. The aluminium filter, holding oil

and dust from the air, is clogged and

should be washed after being soaked

in hot water with an effective detergent

once every 1.5 to 2 months. Changing

the  control  of  the  filter  after  washing

does not affect the quality of its work.

8.6. To remove the aluminium

filter  (Fig.  6),  press  the  spring  lock  of

the  aluminium  filter  1  and  remove  it.

Extract  the  pull-out  panel  with  filter

2  and  remove  the  aluminium  filter  3.

The  filter  installation  is  performed  in

reverse  order.  Do  not  install  the  filter

after washing until it is completely dry.

 8.7 To replace the lamp, it is

necessary  to  remove  aluminium  filter

1,  pull  out  the  panel  with  the  filter  2,

pull the holder of the bulb socket, so

that the lamp 3 came out of the body

of cooker hood, holding the bulb socket,

lightly press the lamp in the direction

of the bulb socket and, turning it

counterclockwise, take out from the

Fig. 6

Replacement of the lighting lamp.

Fig. 7

Aluminium filter removing

body of the cooker hood (Fig. 7). Insted?

it is necessary to install a new one with

the same characteristics and install an

aluminium filter 1.
