UK - Instruction on mounting and use

Consult the designs in the front pages referenced in the text
by alphabet letters.

Closely follow the instructions set out in this manual.

All

responsibility,  for any eventual inconveniences, damages or
fires caused by not complying with the instructions in this
manual, is declined.

Note:

the elements marked with the symbol “(*)” are optional

accessories supplied only with some models or elements to
purchase, not supplied.

Use

The hood is designed to be used either for exhausting or filter
version.

Ducting version

The hood is equipped with a top air outlet

B

 for discharge of

fumes to the outside (exhaust pipe and pipe fixing clamps not
provided).

Fig. 5

Attention!
If the hood is supplied with carbon filter, then it must be
removed.

Filter version

When there is no exhaust duct for venting outdoors, you can
use a carbon filter.
The air is depurated by the filter and put again in the
surrounding. To use the appliance in this version, proceded as
follows:

Attention!
If the hood is not supplied with carbon filter, then it must
be ordered and mounted.

The filtered air is returned from atop the cabinet through a
duct that passes through the cabinet itself.The diameter of the
duct must be the same as that of flange

H

.

The deflector

J

 can be fixed to the outlet hole using the two

screws provided.

Fig. 4-5

Installation

The minimum distance between the supporting surface for the
cooking vessels on the hob and the lowest part of the range
hood must be not less than 43cm from electric cookers and
65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this must be adhered to.

Electrical connection

The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area. If it not fitted
with a plug (direct mains connection) or if the plug is not
located in an accessible area apply a bi-polar switch in
accordance with standards which assures the complete
disconnection of the mains under conditions relating to over-
current category III, in accordance with installation
instructions.

IMPORTANT:

Before re-connecting the hood circuit to the

mains supply and checking the efficient function, always
check that the mains cable is correctly assembled and that it
has NOT remained crushed inside the compartment of the
same during the installation stage.

Mounting

Before beginning installation:

•

Check that the product purchased is of a suitable size for
the chosen installation area.

•  To facilitate installation, remove the fat filters and the

other parts allowed and described here, dismantle and
mount it.

To remove see also the relative paragraphs.

•

Remove the active carbon (*) filter/s if supplied (see also
relative paragraph). This/these is/are to be mounted only
if you want lo use the hood in the filtering version.

•  Check (for transport reasons) that there is no other

supplied material inside the hood (e.g. packets with
screws (*), guarantees (*), etc.), eventually removing
them and keeping them.

•

If possible, disconnect and move freestanding or slide-in
range from cabinet opening to provide easier access to
rear wall/ceiling. Otherwise put a thick, protective
covering over countertop, cooktop or range to protect
from damage and debris. Select a flat surface for
assembling the unit. Cover that surface with a protective
covering and place all canopy hood parts and hardware
in it.

•  Disconnect the hood during electrical connection, by

turning the home mains switch off.

•

In addition check whether near the installation area of the
hood (in the area accessible also with the hood mounted)
an electric socket is available and it is possible to
connect a fumes discharge device to the outside (only
suction version).

•  Carry out all the masonry work necessary (e.g.

installation of an electric socket and/or a hole for the
passage of the discharge tube).

Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood.

Do not tile, grout or silicone this

appliance to the wall. Surface mounting only.

This hood is designed for fitting in a cabinet or on some other
support.
The diameter of the ventilation duct must be the same as the
that of the flange mounted on the ventilation hole on the hood.
To mount the hood proceed as follows:
-

Position the drilling template inside the left cupboard on
the right hand side with the arrow point towards the back
on the cupboard.

-

Drill the holes marked on the template.

-

Repeat the procedure for the right hand cupboard

-

If the sides of the cupboards are 18 mm thick, insert 4
