Gorenje DFG 602 ORA S - Инструкция по эксплуатации - Страница 10

10

film to protect their filtering properties. If this is the case,
remove the film before installing the filter.

b.

  Remove the pull-out drawer completely.

c.

  Remove the grease filters or the grates.

d.

Place the activated carbon filter in position:
1)   Version with one motor: insert the filter in its housing

over the plastic grill and rotate it until it locks in
position (Fig. 6).

2)   Version with two motors: to assemble the filter,

insert it in its seating and fix it in position using the
clips

L

 (Fig. 7)

e.

  Remove the grease filters or grills

To remove the carbon filter, follow the procedure described in
item 1) or 2), depending on the version) in the reverse order.

Replacing lamps

Disconnect the hood from the electricity.

Warning!

Prior to touching the light bulbs ensure they are

cooled down.

a.

  Remove the pull-out drawer.

b.

  Open the light cover support or the back grease filter

support grate.

c.

   Always replace burnt-out lamps, according to what is

provided for your appliance, with olive-shaped max. 40
Watt (E 14) bulbs, or neon-lamp 14 Watt max., or PL
lamp 11 Watt (one PL lamp appliance) or PL 9 Watt (two
PL lamp appliance).

d.

  Close the light cover support or the back grease filter

support grate.

If the lights do not work, make sure that the lamps are fitted
properly into their housings before you call for technical
assistance.

Caution

WARNING!

 Do not connect the appliance to the mains until

the installation is fully complete.
Before any cleaning or maintenance operation, disconnect the
hood from the mains by removing the plug or disconnecting
the home mains switch. The appliance is not intended for use
by children or persons with impaired physical, sensorial or
mental faculties, or if lacking in experience or know-how,
unless they are under supervision or have been trained in the
use of the appliance by a person responsible for their safety.
Children should be monitored to ensure that they do not play
with the appliance.
Never use the hood without effectively mounted grating.!
The hood must NEVER be used as a support surface unless
specifically indicated.
The premises must be sufficiently ventilated, when the kitchen
hood is used together with other gas combustion devices or
other fuels.
The suctioned air must not be conveyed into a conduit used
for the disposal of the fumes generated by appliances that
combust gases or other fuels.
The flaming of foods beneath the hood itself is severely
prohibited.

The use of exposed flames is detrimental to the filters and
may cause a fire risk, and must therefore be avoided in all
circumstances.
Any frying must be done with care in order to make sure that
the oil does  not overheat and burst into flames.
As regards the technical and safety measures to be adopted
for fume discharging it is important to closely follow the
relations provided by the competent authorities.
The hood must be regularly cleaned on both the inside and
outside (AT LEAST ONCE A MONTH, it is in any event
necessary to proceed in accordance with the maintenance
instructions provided in this manual)..
Failure to follow the instructions as concerns hood and filter
cleaning will lead to the risk of fires.
We decline any responsibility for any problems, damage or
fires caused to the appliance as the result of the non-
observance of the instructions included in this manual.
This appliance is marked according to the European directive
2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE). By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for the
environment and human health, which could otherwise be
caused by inappropriate waste handling of this product.

The symbol

 on the product, or on the documents

accompanying the product, indicates that this appliance may
not be treated as household waste. Instead it shall be handed
over to the applicable collection point for the recycling of
electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for
waste disposal.
For more detailed information about treatment, recovery and
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product.
