20

MOUNTING THE RANGE HOOD WITHOUT MOTOR
CHAMBER

1)  Measure the distance (L) from the bottom of the range hood to the centre of the mounting

holes (Fig. 7).

2)  Measure the distance (M) between the two mounting holes.
3)  Line up the centre of the cooktop with the centre of the range hood. Is: L+650 mm.
4)  The height of the holes to be drilled above the cooktop is calculated by adding (L) to (H),

where (H) is defined by point C-1.

5)  Drill the holes for the Fischer screw anchors (the diameter of the holes depends on the type

of screw anchor).

6)  Before hanging and securing the range hood, remove:


- the steel grilles for range hoods with tangential motors

- the entire build-in assembly, if fitted, by unscrewing the screws that secure it to the bot-
tom.

7)  To avoid hood unhooking due to underneath pressure, fix it to the wall with a  screw anchor

and related screw, by using the appropriate holes at the back of the hood or the cope fla-
sks.

8)  Hang the range hood.
9)  Check, through the hole at the bottom, that the range hood is properly anchored to the

Fischer hooks.

10)  Adjust the height of the range hood using the screws on the Fischer hooks.
11)  Fit the steel grilles or the build-in assembly.
12)  Mounting instruction for chimney (fig. 8):


- Fasten bracket (A) to the wall, at the correct distance;

- Fasten the upper part of the extension to bracket (A).
