17

LIGHTING

ASSEMBLY AND REPLACEMENT

I

1. LIGHT BULB

To replace the light bulb:

a)   Make sure the appliance is disconnected from the mains power supply.
b)   Unscrew the support screw A and remove the light cover.
c)   Replace the light bulb with the same model as the original (max 25 W, see the markings

near the light).

A

  WARNING! Light bulbs with different shapes and power ratings from the original may seri-

ously damage the light compartment.

2.   SPOTLIGHT

To replace the lamp for “Round halogen light”:
a) Make sure the appliance is disconnected from the mains power supply.
b) Remove, by levering with a screwdriver, the support ring A for the cover glass.
c) Remove the cover glass B to access the light compartment.
d) Replace the lamp with the same type (halogen, max 20 W, 12 Volt, G4 fitting).
e) Replace the glass cover B and fasten it using the special ring A.

Round halogen light

How to replace a square halogen light:
a)  Check that the equipment is disconnected from the power supply.
b)

Open the panel completely till 90° (see figure)

 pressing the PUSH button

c)  Replace the lamp with a similar one (halogen, max 20 W, 12 Volt, G4 connection).
d) Close the panel. If the panel does not close correctly repeat the operation at point b.

English
