16

SPEED - Switch B

This is used to start and set the speed of the motor, from 1 to 3, or with continuous speed
variator, depending on the version.

LIGHT - C

Motor operation indicator light.

2.  FIVE BUTTON CONTROL PANEL

 LIGHT-

button

Pressed: the light is on

Released: the light is off

MOTOR button - 1, 2, 3, OFF

1: starts the motor at minimum speed

2: starts the motor at medium speed

3: starts the motor at maximum speed

OFF: stops the motor

FILTERS

REMOVING AND REPLACING’S INSTRUCTIONS

H

1.   METAL FILTERS

To remove the metal grease-trapping filter, simply pull the handle A until releasing it from
the front guide; then tilt it slightly downwards, and slide it out of the rear guide. To reposi-
tion the filter, repeat the operation in the reverse order.

A

2.   CHARCOAL FILTERS

To replace the charcoal filters, proceed as follows: remove the metal filters as described
above. The two filters located at the ends of the motor can now be easily accessed.

To install the new fi lters see picture.

In case of hood with the motor box the fi lter is located on the botton part of the motor box.

To install the new fi lters see picture.

To order new charcoal fi lters contact the distributor/retailer.

VALID ONLY FOR ITALY:

 download the appropriate order form from: www.falmec.com (access

the assistance drop-down menu).
