EN - Instruction on mounting and use

Closely follow the instructions set out in this manual.

All

responsibility,  for any eventual inconveniences, damages or
fires caused by not complying with the instructions in this
manual, is declined. The extractor hood has been designed
exclusively for domestic use.

Use

The hood is designed to be used either for exhausting or filter
version.

Ducting version

The hood is equipped with a top air outlet

B

 for discharge of

fumes to the outside (exhaust pipe and pipe fixing clamps not
provided).

Fig. 5

Attention! If the hood is supplied with carbon filter, then it
must be removed.

Filter version

When there is no exhaust duct for venting outdoors, you can
use a carbon filter.
The air is depurated by the filter and put again in the
surrounding.

Attention! If the hood is not supplied with carbon filter,
then it must be ordered and mounted.

The filtered air is returned from atop the cabinet through a
duct that passes through the cabinet itself.The diameter of the
duct must be the same as that of flange

H

.

The deflector

J

 can be fixed to the outlet hole using the two

screws provided.

Fig. 4-5

Description of the hood

Fig. 1.1
1.

Light Switch

2.

Motor Speed Switch

3.

Illumination of the cooking surface

4.

Grease Filters/grease filter support grate

5.

  Light Cover Supports

6.

 Pull-Out

Drawer

Model with Grease Filter Support Grate

Opening the Grease Filter Support Grates

 - Fig. 2.1

a.

  Remove the pull-out drawer completely.

b.

 Push

the

A

 knobs inwards toward each other (in the

“Open” direction as indicated on the plastic knob itself).

c.

  To remove the grates completely, use the

B

 spring

fasteners, which act as pins to hold the grate in place
(Fig. 3).

Model with Self-supporting Metal Filters

Removing the Grease Filters

 - Fig. 2.2

a.

  Remove the pull-out drawer completely.

b.

Press the side handles

C

 (some models are supplied with

handles Z - Fig. 2.3) towards the opposite side and
remove the filters.

Putting the Filters Back in Place

a.

  Remove the pull-out drawer completely and mount the

grease filter so that it covers the drawer.

b.

  Close the drawer and install the remaining grease filter.

Opening the Light Cover Support

a.

  Remove the pull-out drawer completely.

b.

   According to model in possession:

 Lamp

D

 with hook locks type

A

 - Fig.2.2

Move the bracket hook locks towards each other  (in
direction “Open” as printed on the plastic part of the lock).
Lamp

F

 with hook locks type

S

 - Fig. 1.2

Move the hook locks as indicated by the arrows and
completely remove the lamp from the housing (Fig. 1.3).

  Caution

Keep this use manual with your apparatus. If the apparatus
has to be sold or ceded to someone else, make sure that this
manual is also sent.
Read this manual carefully before installing or using your
apparatus because it contains important information for your
safety and for whoever installs or uses it.
This apparatus has been created to be installed in a kitchen
and for normal domestic use.
Do not use it for commercial or industrial purposes or other
purposes for which it was not created.
Do not modify or try to modify the characteristics of this
apparatus. It would be dangerous for you.
Using over a fuel (wood, carbon) cooking top is not
authorised.
If the filtering hood is installed in a kitchen heated by an
apparatus connected to a fireplace (e.g. a stove), the filtering
