12

Operation

The hood is fitted with a control panel with aspiration speed selection control
and a light switch to control cooking area lights.
Use the high suction speed in cases of concentrated kitchen vapours.  It is
recommended that the cooker hood suction is switched on for 5 minutes
prior to cooking and to leave in operation during cooking and for another 15
minutes approximately after terminating cooking.



The control switches are located on the hood’s front panel:

A.

  OFF – ON push button

Press once or more to obtain the function desired:

ON: the hood switches on to the last speed selected.

OFF: all the functions are switched off except the illumination.

B.

  Speed selection push button (extraction power).

Press this push button once or more to select the most suitable
extraction speed (power) (1-2-3).

C.

  The display shows the extraction power selected, signalling the

saturation

 of the filters

F

.

D.

  Intensive speed on/off. The Intensive speed runs for 5 minutes:

If the hood is on when the Intensive speed is activated, the hood
reverts to previous speed after 5 minutes.

If the hood is off when the Intensive speed is activated, the hood will
be turned off after 5 minutes.

To interrupt the Intensive speed, press button

A

 or

B

.

E.

 Light

ON/OFF


Should the hood or the controls fail to operate: disconnect the power supply
for at least 5 seconds, then turn the hood back on again.


Grease and charcoal filter maintenance indicator - DU 4561

This hood is fitted with a device that indicates when it is necessary to clean
the grease filter or the charcoal filter (if the hood is used in the recirculation
version with a charcoal filter).
On delivery, the hood is not supplied with a charcoal filter, so the saturation
indicator will be disabled.
If the hood is to be used with a charcoal filter, the saturation
indicator light must be enabled as follows:
Set the hood in “OFF”.
Pressing keys

B

 and

D

 simultaneously for three seconds,

LED F

 lights up

and begins to flash the 1st speed led.  After 1 second the 2nd speed led also
flashes and the system emits a sound signal (-Beep-) to indicate setting
taking place.
To remove the charcoal filter signal press push buttons

B

 and

D

simultaneously for 3 seconds.

LED F

 lights up and begins to flash the 1st

speed led (grease filter) and the 2nd speed led.  After 1 second, only the 1st
speed led continues to flash.  The system emits a sound signal (-Beep-) to
indicate setting taking place.


Grease filter LED

The 1st speed led (+

led F)

 flashes, when it is time to clean the grease filter.

Always comply with the maintenance instructions for the grease filter.


Charcoal filter LED

The 2nd speed led   (+

led F)

  flashes, when the charcoal filter needs to be

cleaned or replaced.


Resetting the saturation indicator

After cleaning or replacing the filters, press button

1

 for 3 seconds until  the

1st speed led or the second speed led stops flashing.
The

F LED

 also turns off.

Maintenance
ATTENTION!

Before performing any maintenance operation, isolate the

hood from the electrical supply by switching off at the connector and
removing the connector fuse.
Or if the appliance has been connected through a plug and socket, then the
plug must be removed from the socket.
The cooker hood should be cleaned regularly (at least with the same
frequency with which you carry out maintenance of the fat filters) internally
and externally.  Clean using the cloth dampened with neutral liquid
detergent. Do not use abrasive products.

DO NOT USE ALCOHOL!

WARNING:

Failure to carry out the basic cleaning recommendations of the

cooker hood and replacement of the filters may cause fire risks.
Therefore, we recommend oserving these instructions.
The manufacturer declines all responsibility for any damage to the motor or
any fire damage linked to inappropriate maintenance or failure to observe
the above safety recommendations.


Grease filter
Fig. 1-20
The grease filter

 must be cleaned once a month using non aggressive

detergents, either by hand or in the dishwasher, which must be set to a low
temperature and a short cycle.  When washed in a dishwasher, the grease
filter may discolour slightly, but this does not affect its filtering capacity.


Charcoal filter (filter version only)
Fig. 19

The saturation of the charcoal filter occurs after more or less prolonged use,
depending on the type of cooking and the regularity of cleaning of the grease
filter.
In any case it is necessary to replace the cartridge at least every four
mounths.
The charcoal filter may NOT be washed or regenerated.

Type 150 - Washable activated charcoal filter

The charcoal filter can be washed once every two months using hot water
and a suitable detergent, or in a dishwasher at 65°C (if the dishwasher is
used, select the full cycle function and leave dishes out).
Eliminate excess water without damaging the filter, then remove the
mattress located inside the plastic frame and put it in the oven for 10 minutes
at 100° C to dry completely. Replace the mattress every 3 years and when
the cloth is damaged.

Type 60/80 - NON-washable activated charcoal filter

The saturation of the charcoal filter occurs after more or less prolonged use,
depending on the type of cooking and the regularity of cleaning of the grease
filter.
In any case it is necessary to replace the cartridge at least every four
mounths.
The charcoal filter may NOT be washed or regenerated.


Replacing lamps
Fig. 21

Disconnect the hood from the electricity.

Warning!

Prior to touching the light bulbs ensure they are cooled down.

Replace with a new 12 Volt, 20 Watt (Maximum) halogen light made for a G-
4 base SUITABLE FOR USE IN OPEN LUMINAIRES.  Follow package
directions and do not touch new light with bare hands.
