1. Check the power plug and outlet as often as possible. Secure electrical

contact and also proper grounding must be provided. The plug and outlet

must not heat excessively.
2. If the water heater is not used for a long time, especially in regions with

low air temperature (below 0°C), it is necessary to drain water from the

heater to prevent damage of the water heater (due to water freezing in the

internal tank).
3. To ensure long reliable water heater operation, it is recommended to

regularly clean the internal tank and remove deposits on the electric heating

element of the water heater, as well as check condition (fully decomposed

or not) of the magnesium anode and, if necessary, replace it with a new one

in case of full decomposition.
4. Tank cleaning frequency depends on hardness of water located in this

territory. Cleaning must be performed by special maintenance services.

You can ask the seller for address of the nearest service center or find it on

the website www.timberk.com.

Preventive operations must be performed upon strict observance of the

operation manual and safety precautions.
5. The water heater is equipped with a thermal switch, which cuts off power

supply of the heating element upon water overheating or its absence in the

water heater. If the water heater is connected to the mains, but water is

not heated and the indicator doesn’t light up, then the thermal switch was

switched off or not switched on. To reset the water heater to the operating

condition, it is necessary to:
- de-energize the water heater, remove the plate of the side / lower cover.
- press the button, located at the center of the thermal switch, Fig.10 ;
- if the button is not pressed and there is no clicking, then you should wait

until the thermal switch cools down to the initial temperature.

IMPORTANT!

The manufacturer provides an extended guarantee

for particular water heater components provided that

timely and proper routine maintenance is performed

by specialists of an authorized service center (see the

guarantee slip).

6. Water can be drained through a composite relief valve (Fig.9 ) (unscrew

the composite relief valve drain knob screw and set the drain knob to the

upper position, at that hot water tap must be open, and cold water supply

valve must be closed).

7. Bear in mind to check serviceability of the relief valve every 14 days –

inspection method:
- turn the discharge lever to the left up until you feel the change of thread,

then water must start flowing from the valve’s hole. After checking the

water flow, return the lever to its initial position.

IMPORTANT!

If these actions had no positive result or the thermal

switch turns off repeatedly during a short period of

time, then you should de-energize the water heater,

cut off water supply and contact your local Timberk

Authorized Service Center for a consult or repair of the

appliance.

IMPORTANT!

Never drain water if its temperature is over 50°C since

it may result in burns.

8. If necessary, wipe external surfaces of the heater by a damp cloth with

soap.

IMPORTANT!

If water doesn’t flow, then the valve is damaged.

In this case you must not use the heater and it is

recommended to call for a service technician.
