5. MAINTENANCE

6. WARRANTY (EN)

VS 500

Legal guarantee

2 years

Additional commercial warranty on tanks

+ 1 years

Type / Reference:

STAMP DEALER

Serial number:

Name and address of customer:

-

Before removing the plastic cover, make sure the power is turned off to avoid any risk of injury or electric shock

.

The domestic maintenance

 must be done by the user. Operate the safety device every month to prevent scaling and check

that it’s not blocked. Not executing this maintenance may cause damage and the loss of the warranty.

Maintenance by

qualified personnel

 A:

Scaling: Remove the scale deposited as mud. Do not scratch or hit the scale sticking to the walls to

avoid damage to the coating. Do not forget to change the seal and reassemble the appliance, check that there is no leakage of

water after the first heating.

B:

For devices with magnesium anode, change the magnesium anode every two years or as soon

as its diameter is less than 10mm.

C:

 The change of a sheathed heating element involves draining of the water heater and the

change of the seal. Reassemble the heating element, reasonably tight nuts (cross tightening), check that there is no leakage

after the first heating-up, and tighten again if necessary.

D:

 Drain: Turn off power and cold water supply, Open hot water taps

and drain valve of the safety device.

-

The replaceable parts are: thermostat, gasket, heater element, magnesium anode,and cover

.

Warranty is subject

to the use of original spare parts from manufacturer. ADVICE TO THE USER:

 In case of hard water with TH> 20 ° f

(>200 ppm), we recommended to soften the water. If a water softener is used, the remaining water hardness should be more

than 15 ° f. In the case of a longer absence and especially in winter, drain your device, and then follow the procedures for

starting-up.

- The water heater must be installed, operated and maintained in accordance with the state of the art and with the standards

in force in the country of installation and the instructions in this manual.

 In the European Union

 this unit has the legal

guarantee granted to consumers under Directive 1999/44/EC, this warranty is effective from the date of delivery of the

goods to the consumer. In addition to the legal guarantee, some products have an extended warranty, limited to the free

replacement of the tank and components recognized as defective

,

excluding replacement and transport cost

. Refer to the

table below

.

This warranty does not affect any rights you may benefit as a result of the application of the statutory warranty.

It applies in the country of purchase of the product, provided it is also installed on the same territory. Any damage must be

reported to the depositary before exchange under warranty, and the unit will remain available to insurance experts and the

manufacturer.

-

Exclusions:

 Wear parts: magnesium anodes … Equipment which cannot be accessed (access difficult for repair,

maintenance or assessment).

Devices exposed to abnormal environmental conditions: frost, outdoor weather, water with

abnormal chemical characteristics outside drinking water criteria, mains network with power peaks.

 Equipment installed

without observing current standards in the country of installation: absence or incorrect safety device, abnormal corrosion due

to incorrect hydraulic fittings (iron/copper contact), incorrect earthing, inadequate cable thickness, non-observance of the

connection drawings show in these instructions. Equipment not maintained in accordance with these instructions. Repairs or

replacement of parts or components in the equipment not carried out or not authorised by the company responsible of the

guarantee. Change of a component does not extend the warranty period for the device. The warranty shall apply to products

that are defective and appraised by the company liable for warranty. It is compulsory to keep the products available to the

latter.

- To claim under guarantee,

contact your installer or dealer.

 If necessary, contact: ATL International Tel: (+33)146836000,

Fax: (+33)146836001, 58 av Gén. Leclerc 92340 Bourg-la-Reine (France), Tel: 0080038713858 (Belgium) who will inform you

of what you should do.
