1. INSTALLATION

2. HYDRAULIC CONNECTION

3. ELECTRICAL CONNECTION

4. STARTING UP

Diameter  Vertical installation

VS 500

See fig.

- For vertical installation of Ø 505 devices if the wall is not strong enough, an optional ground support is available.

Nevertheless, it is mandatory to fix the unit to the wall with the top bracket to avoid tipping.

- For horizontal installation, the water connection tubes must always be in a vertical position below the device.

-  It is necessary to clean the supply piping prior to the hydraulic connection. The connection to the hot water outlet is to

be carried out with a cast iron or steel sleeve or a dielectric connector, to avoid corrosion of the pipe (direct contact iron /

copper). The use of brass fittings is prohibited.

1.22  INSTALLATION PRESSURISED

: See fig.   , p. 3. Always install a new safety device on the cold water pipe of the

water heater, which comply with the standards (EN 1487 in Europe), with a pressure of 0.7 or 0.9 MPa (7 or 9 bar) according to

the nominal pressure, with

diameter

 1/2" or 3/4" (Table p. 3). If expansion down the mains is required, the safety valve and/or

pressure reducing valve must be 3 mts from the water heater.

- During heating up, water

dripping

 may occur at the valve, do not obstruct the dripping

.

- Refer to the corresponding diagrams p.4 (See fig.

 ).

- The water heater can be connected and operated only on AC 230V. Connect the heater with a rigid cable with conductors

2,5mm ². Use a standardised channeling (rigid or flexible conduit) until the calibrated housing cover.

- Directly connect devices with a cable or plug. In France, a product with plug is strictly prohibited and cannot be sold and

installed.

- Always connect the earth conductor of the cable to the earth ground wire or connect the earth conductor to the appropriate

terminal identified by the symbol . This connection is compulsory for safety reasons. The earth wire green - yellow must be

longer than those of phases. The installation must be equipped, upstream of the appliance, with a bipolar cut-out device

(minimum contact distance of 3 mm fuse, breaker switch). In the case where HYDRAULIC connexions are in insulated

material, electrical circuits shall be protected by a differential circuit breaker 30 mA adapted to local standards.

-

Thermal circuit breaker:

 All products are equipped with a thermostat including a thermal circuit breaker with manual reset,

which cuts the power in case of overheating. In case the security trips

A

: Cut the power before any operation.

B:

 remove

the plastic cover.

C:

 Check the electrical connection.

D:

 Reset security. In case of repetitive tripping, replace the thermostat.

Never bypass safety or regulation thermostat. Connect the power only on the sockets or thermostat input.

-

NEVER POWER THE WATER HEATER WITHOUT WATER:

 Models with an electric heating element will be certainly

damaged.

- Fill the tank completely. Before powering up, open the hot water taps, drain the pipes in order to empty the air.

- Check the tightness of the tubes and of the flange seal under the plastic cover. In case of leaking tighten moderately.

Check the operating of the hydraulic components and of the safety valve.

- Turn the power on. After 15 to 30 minutes, depending of the capacity of the device, the water should drip from the drain.

This is normal and due to the expansion of water. Check connection leaks and seal. During heating and according to the

water quality, hot water tanks can make a bubbling noise. This noise is normal and does not indicate any defect of the unit.

The thermostat is factory set to stop at 85 ± 5 ° C.

If you see a continuous release of steam or hot water from the drain

or when opening a faucet, turn off immediately the power to the water heater and call a professional.

-

For easy adjustment of 4 positions

Position:

     Antifreeze protection of the water heater (max 30 ° C). This position does not cause the heating

element to be switched off
Position:           Approximately 40 ° C (Warm Water)

Position:

      Approx. 65 ° C (Hot Water)

Recommended position

Position:

   About 85 ° C (very hot water)

Take precautions to avoid burns

- Refer to the corresponding diagrams p.3 (see table on right):

- Make sure to keep free space of 300 mm below pipes for the exchange of the heating

element.

1.21

Do not dispose your water heater in the garbage, but hand

it to a place assigned for this purpose (collection point)

where it can be recycled.

1.22

The instruction book of this product is available by

contacting the after-sales service.
