24

For users and contractors

1.1

Equipment description

The฀instantaneous฀water฀heater฀DDLE฀Basis฀heats฀water฀as฀it฀lows฀through฀the฀equipment.฀You฀can฀adjust฀

the DHW outlet temperature anywhere between approx. 30 °C and approx. 60 °C via a temperature selector.
From a flow rate of approx. 3 l/min onwards, the control regulates the correct heating output, subject to the
temperature selection and the cold water temperature.

1.2

Vital facts in brief

•฀Temperature฀selector

Turning฀the฀selector฀lets฀you฀freely฀choose฀the฀required฀temperature.

  Wash basin ( 35 °C )

  Shower ( 40 °C)

  Bath ( 45 °C )

  Sink ( 55 °C )

฀Should฀the฀outlet฀temperature฀fail฀to฀reach฀the฀required฀level,฀when฀the฀tap฀is฀fully฀opened,฀and฀the฀

temperature selector has been set to maximum (temperature selector turned fully clockwise), then more water

lows฀through฀the฀equipment฀than฀can฀be฀heated฀by฀the฀internal฀heater฀cartridge฀(output฀limit฀18,฀21,฀24฀or฀

27 kW). In such cases, reduce the flow rate at the tap accordingly.

•฀Temperature฀limit

A฀contractor฀can฀set฀the฀temperature฀limit฀to฀43฀°C฀at฀the฀device.฀You฀can฀still฀adjust฀the฀temperature฀selector฀

across its entire range. The outlet temperature will be permanently limited to 43 °C.
A temperature range 30 °C to 43 °C can be selected.

1.3

Safety information

฀There฀is฀a฀risk฀of฀scalding฀at฀outlet฀temperatures฀in฀excess฀of฀43฀°C.

Where children or persons with limited physical, sensory or mental capabilities are to be allowed to control

this฀equipment฀ensure฀that฀this฀will฀only฀happen฀under฀supervision฀or฀after฀appropriate฀instructions฀by฀a฀

person responsible for their safety. Children should be supervised to ensure that they do not play with the

equipment฀-฀risk฀of฀scalding.

1.4

Important information

If฀the฀water฀supply฀to฀the฀instantaneous฀water฀heater฀has฀been฀interrupted,฀e.g.฀because฀of฀a฀risk฀of฀frost฀

or฀work฀on฀the฀water฀system,฀take฀the฀following฀measures฀prior฀to฀taking฀the฀equipment฀back฀into฀use:

1.  Remove fuses or trip the appropriate MCBs.

2.฀ Open฀a฀tap฀downstream฀of฀the฀equipment฀long฀enough,฀until฀all฀air฀has฀been฀vented฀from฀the฀equipment฀

and its cold water supply pipe.

3.  Replace the fuses or reset the relevant MCBs.

1.

Operating instructions

Thank฀you฀for฀purchasing฀this฀instantaneous฀water฀heater฀from฀AEG฀Haustechnik.฀You฀have฀chosen฀a฀

high-grade device made in Germany.
Even during the development and manufacture, AEG Haustechnik recognises the high value of manufacturing
processes that are environmentally responsible and treat resources with care. Thanks to many product

innovations,฀devices฀made฀by฀AEG฀Haustechnik฀are฀amongst฀the฀most฀energy-eficient฀in฀their฀class.

!

!
