slightly open at the side towards
the ventilation. If you value clear
contours and unrestricted head ­
room in your kitchen, down ­
draft ventilation is definitely the
most unobtrusive solution. The
design of Gaggenau downdraft
ventilation units is the per fect
match for cooktops from the
Vario 20 0 and 40 0 series. They
are also available with an ex­
tendable swivel arm and sealing
flaps. All downdraft ventilation
units are configured with sepa­
rate fan units for air ex traction
purposes.

Dr ying programme

With this function, the inside
of the Combi ­ steam oven can
be dried with hot air. The dr ying
procedure takes about 20 min ­
utes and is recommended after
each steaming or cleaning pro ­
cedure.

Dynamic cold air distribution

A ventilator ensures an even
temperature distribution across
the whole cooling compar tment,
thus ensuring longer food ­ stor­
age times. With dynamic cold
air distribution with Multi ­ Air­
Flow, an additional air channel
in the door and additional vents
in the cooling compar tment en ­
sure faster and more constant
temperature distribution.

E

Eco

In this operating mode, all
energy­ dependent functions of
the oven are optimised to make
them especially energy­ saving.
For example, the light is switched
off or any available residual heat
is used for baking or roasting.

Electric grill

Independently controlled
heating elements: This enables
you to grill in the front section
while the rear section is used
for keeping warm. Both glow
bars can be folded up for clean ­
ing the lava stone container.
With the 400 series wire rack, the
heating elements are covered
so that smoke emissions are very
low since grease is prevented
from dripping onto the heating
elements.

Stainless steel container
with lava stones: With a per­
forated base so that grease
can drip into the removable drip
tray. The stainless steel con ­
tainer and the grease drip tray
can be cleaned in the dish ­
washer. The lava stones need to
be changed when they become
heavily soiled.

Solid cast roaster: Practical
accessor y  for  grilling  and
 cooking  on  a  smooth  sur face,
e.g.  shrimps,  or  vegetables.
Also just the thing for preparing
egg ­ based dishes such as pan ­
cakes or crêpes.

Electric ignition

By pressing the knob, the flame
is ignited automatically. This
then needs to be held down
briefly until the thermoelement
reaches the temperature re ­
quired for a stable flame. It has
a thermoelectric safety pilot
to keep the gas flame burning
constantly. If the flame goes
out, the gas supply is interrupted
automatically.

Electronic boiling point
detection

This calibration enables the
electronic system to detect the
boiling point automatically.
This enables the same cooking
results to be achieved, regard ­
less of the altitude of the instal ­
lation location above sea level.

Electronic flame monitoring

If the flame is ex tinguished ac ­
cidentally, it is reignited imme ­
diately and should automatic
reigniting fail, the gas supply
for all burners is interrupted im ­
mediately: Ma ximum safety due
to the principle of ionisation.

Electronic temperature
 control

Precise temperature control
prevents temperature peaks in
ovens which might impair cook­
ing of delicate dishes. With
cooling appliances, precise tem­
perature setting enables longer
storage times. Operation of all
settings and special functions is
via the keyboard, and the tem ­
perature is displayed digitally.

Energy consumption

The energy consumption of a
cooling appliance is determined
according to the German DIN
EN 153 standard, at 220 V/50 Hz.
The value for energy consump ­
tion per year is shown, as is the
value for energy consumption
for 10 0 litres of net volume per
day. The latter enables applian ­
ces of various sizes to be com ­
pared;  deviations  may  occur
during  ever yday  operation.

Energy label

This is a Europe ­wide code for
the energy efficiency class
and provides information about
the energy consumption of ap ­
pli ances. The different classes
in dicate how economical a par­
ticular appliance is compared
with the overall average. Par ti ­
cularly economical appliances
are graded as energy efficiency
classes A and B – or even A++
and A+ for cooling appliances
and freezers. For dishwashers,
there is a fur ther classifica­
tion alongside the energy effi ­
ciency class – the so ­ called
Euro label rating also the clean ­
ing efficiency and dr ying effi ­
ciency of different appliances.
All Gaggenau dishwashers bear
the A A A label. This is awarded
to appliances that are par ticular­
ly energy­ efficient while deliver ­
ing exceptional cleaning and dr y­
ing per formance.

F

Fan unit

Downdraft ventilation units and
ventilation hoods are operated
via a separate fan. Fan units can
be installed, depending on the
construction type, in kitchen
furniture, in another adjoining
room, in the cellar, loft or out­
side (on a wall or roof). All func ­
tions are controlled via a cable,
as with an integrated fan.

Fast cooling

Similar in function and effect to
the fast freezing function. Auto ­
matic fast­ cooling generates the
ma ximum chilling power, there ­
by minimising the warming up
of items already stored in the
refrigerator when new items are
added. The  appliance  auto ma t­
ically rever ts to the standard
mode.

Solid cast roaster.

 Practical

 accessor y for grilling and
 cooking on a smooth sur face.

Door opening angle in the
Vario cooling 40 0 series

The wide ­ opening doors, which
open to a 115 degree angle, are
truly unique – the par ticularly
sturdy hinges make it possible.
The drawers and shelves are
already  fully  ex tendable  at  an
angle of 90 degrees.

Door panel
(special accessor y)

Designed to match the 200 series
ovens, a stainless steel or alu ­
minium ­ backed full glass door
panel is available for all 81.5 cm
and 86.5 cm high dishwashers.

Dosage assist

Integrated into the top basket,
the dosage assist ensures that
detergent tablets are fully dis ­
solved in a controlled manner.
This is a prerequisite for en sur­
ing the best possible clean ing
results. Tablets can no lon ger
fall between plates or into the
cutler y basket. What’s more, the
dosage chamber is positioned
in a way that prevents scraps of
food from dropping into it dur­
ing loading. Yet another advan ­
tage: the jet spray no longer
directly hits the inner door and
the appliance is quieter.

Downdraft ventilation

An interesting and highly­ effec ­
tive alternative to classic ven ­
tilation hoods. Downdraft venti ­
lation is integrated directly into
the cooktop and it siphons
off cooking vapours right there
where  they  emerge.  Even  the
steam  from  tall  pots  is  ef fec ­
tively  removed  if  the  lid  is  left.

Downdraft ventilation.

 A highly­

effective alternative to classic
ventilation hoods. Downdraft
ventilation is integrated into
the cooktop and it siphons off
cooking vapours right there
where they emerge.

Fast freezing

This ma ximum power setting is
for the quick freezing of unfrozen
items, while also preventing al ­
ready frozen items from warming
up when new items are added to
the compar tment. What’s more,
fast freezing has a beneficial im ­
pact on the durability and qual ­
ity of frozen food after thawing.
This setting ensures that the
cell structure of frozen food is
not damaged by the freezing
process, thereby preser ving the
food’s taste and freshness. The
appliance automatically rever ts
to the standard mode.

Fast ignition

Press the knob on the gas
cooktop, turn to the desired
setting and release – the elec ­
tronics immediately ignite the
flame and keep it burning with ­
out the user having to keep the
knob pressed.

Fixed inlet and outlet  water
connection

When being fitted, the Combi ­
steam oven is connected direct­
ly to the water inlet and outlet.
This means that fresh water is
always available for all cooking
tasks and that you don’t have to
fill and empty a water tank.

Flex Plus basket system

For greater versatility and con ­
venience when loading and
unloading. This system is par ti c ­
ularly flexible and can accom ­
modate plates with a diameter
of up to 33 cm. All dishwashers
with 6 programmes feature this
system as standard.
