Once the maximum allowed power level that can be set is

reached, the display in the zone being used shows the letter

“

r

” after which it automatically sets the lower power level

allowed. It is possible to use multiple zones at the same time,

keeping the respective levels so that total power does not

exceed what is allowed.

Key Function (Fig.2B):

To prevent children or people- requiring supervision- from

using the cooktop, all functions can be blocked with the

“

B

” button.

- To   a c t i v a te   o r   d e a c t i v a te,   p re s s   t h e  “

B

”  b u t to n   fo r

approximately 2 seconds. The function is activated when the

“

B1

” indicator is turned on.

- If the appliance is on and the key function is activated, the

“

A

” button works in the same way.

- If the hob us shut off with the key function active, the next

time it is started the hob will have the same engaged therefore,

deactivate the key function “

B

”.

- It is possible to activate the key function even is if the hob is

shut off, using the key button “

B

”.

- The “

B

” key function activates automatically every time that

power is take away, in order to use the hob at that point it is

necessary to deactivate it.

Booster (Fig.2):

Depending on the appliance model, it may be fitted with a

Booster

 system which can be used to speed up cooking times

through the application of a power level which is greater than

the nominal value, within a defined period of time.

The heating plates equipped with this function are labelled

with the word “

Booster

”.

In order to activate it bring the power level to 9, then press the

“

+

” button. The letter

“

P

” will appear on the display.

If  the “

+

” button is pressed once again within the period the

function is active, an acoustic signal is given as a warning.

This function lasts about 10 minutes, at the end of which

cooking continues at level 9.

The “

Booster

” can be activated on all zones.

To interrupt the “

Booster

” function, before the established

time (about 10 minutes), select the desired zone and press the

“

-

”

button, cooking will continue at the desired power level.

All these operations will be accompanied by a “BEEP” acoustic

signal.

O.S.D. (Overflow Safety Device) (Fig.2):

The cooktop has a safety system that turns all the plates

OFF

and activates the

safety lock

if any liquid or objects are found

on the control area.

The cooktop goes off automatically.

Magnetic detector (Fig.2):

The hob is equipped with a detector for pans, when they are

removed or unsuitable, the “ ”

symbol appears alternate with

the set power level.

Maintenance (Fig.5):

Remove any residues of food and drops of grease from the

cooking surface using the special scraper supplied on request.

Clean the heated area as thoroughly as possible using SIDOL,

STAHLFIX or similar products and a cloth/paper, then rinse

with water and dry with a clean cloth. Using the special scraper

(optional) immediately remove any fragments of aluminium

and plastic material that have unintentionally melted on

the heated cooking area or residues of sugar or food with a

high sugar content. In this way, any damage to the cooktop

surface is prevented. Under no circumstances use abrasive

sponges or irritating chemical detergents such as oven sprays

or stain removers.

THE MANUFACTURER DECLINES ALL RESPONSIBILITY

FOR EVENTUAL DAMAGES CAUSED BY BREACHING THE

ABOVE WARNINGS.

- 22 -
