conformity with the laws and regulations in force.

Positioning (Fig.3):

The appliance is made for fixing into a worktop, as shown in

the relevant figure. Apply the supplied sealant to the entire

perimeter of the hob and insert it into the fitment hole (for

sizing see Fig.3B). Lock the appliance on the work top using

the 4 supports and the “

V

” holes, rotating them based on

top thickness (Fig.3A). After installation, if the bottom part

of the appliance is not accessible, it is mandatory to install

a separator panel

“

G

” (Fig.6A) following indicated distances

(Fig.6B). If the appliance is installed over an oven the panel is

not necessary (Fig.7A - Fig.7B).

Important:

 if there is an oven under the induction hob it is

advisable for it to have a cooling fan. Do not use the induction

hob while

PYROLITIC

 cleaning is in process.

Warning:

 to allow the circulation of as much fresh air as

necessar y, there must be at least

 40 mm

between the

induction hob module and any appliance installed under

it (Fig.7B).

In any event, adequate aeration must be provided.

To allow fresh air circulation there must be openings in the

kitchen furniture (Fig.6A - Fig.7A) of the sizes indicated in

Fig.6B - Fig.7B.

Electrical connections (Fig.8):

Before making the electrical connections, check that:

- the ground cable is 2 cm longer than the other cables;

- the system ratings meet the ratings indicated on the

identification plate fixed on the lower part of the worktop;

- the system is fitted with efficient earthing compliant to the

laws and regulations in force.

If the appliance is not fitted with a cable, use type:

“

H05V2V2-F

” for a power level of up to 6400 Watts. The

cross-section of the cable should be at least 2.5 mm², or 4

mm² for greater power levels. The cable should never reach

a temperature which is 50°C above the temperature of the

room in which it is installed. The appliance is designed for

permanent connection to the electricity supply and should

therefore be fitted with an omnipolar switch which has a

minimum opening of 3 mm between contacts. The switch

should be suitable for the charge indicated on the appliance

data plate and must conform to all current legislation (the

yellow/green earth wire must not be interrupted by the

switch).

The omnipolar switch must be easy to reach once the

installation process has been completed.

 USE AND MAINTENANCE

Use

(Fig.2):

A       =

ON/OFF

button

B       =

Key

 button

B1 =  Key button ON/OFF

 indicator

C       =

 “

-

” button

D      =

“

+

” button

E    = Heating plate

 selection button

L      =

Display

Cooktop Ignition:

- Verify  that

“

B1

” led is off before turning the equipment

on; otherwise, turn it off by pressing the “

B

” key button for

approximately 2 seconds.

- Next, select the “

A

” button.

- An acoustic signal “BEEP” is emitted after which on all displays

“

L

” decimal points appear “

•

”. If no operation is performed

within this time interval, the hob switches off.

Heating Plate Ignition:

- A heating plate can be turned on by selecting one of the “

E

”

buttons. A blinking zero will appear on the display.

- Use “

+

”  or “

-

” buttons to regulate the power level.

- If the display shows zero and the “

-

” is pressed, the power

level goes directly to 9. The display will show the respective

numbers; those in the interested area, the shade will be bright,

while the other areas will be a lighter shade.

- If after about 10 seconds no operation is carried out, display

shade goes back to the initial one. The hob will continue its

normal cooking.

- If the power level is set at zero, the cooking zone will shut off.

Shutting off the heating plates:

- Select the cooking zone using the button “

E

”. The display will

show the respective numbers; those of the interested area will

be brighter, while the other ones will be a lighter shade.

- Press  the  “

+

” and

“

-

”

buttons simultaneously otherwise, by

selecting only the “

-

” button, it is possible to bring the power

level to zero.

- All operations will be combined with a “BEEP” acoustic signal.

- When a cooking zone “

E

” is brought to the OFF position and

the glass top temperature is greater than approximately 50°,

the  display “

L

” of the interested zone will signal a fixed “

H

”.

Warning:

To prevent damage being inflicted on the electronic circuits,

the hob is fitted with an overheating safety system.In

situations where the appliance is used at high power levels for

a prolonged period of time, the hob may switchoff one or more

of the activated zones temporarily, until the temperatures

return to the set levels. The display of the zone temporarily

shut off will show a “

C

” alternated with the power level. Once

the temperatures are back within the limits, a flashing letter

“

C

” will appear.

Power limiting:

The device is equipped with a power limitation system at

5200, 2800 or 3500 Watt.

The product can be set up with the following instructions:

- Disconnect and reconnect the appliance to the domestic

power supply.

- Select the

“

B

” button within 30 seconds after the reconnection

to the domestic power supply.

- Simultaneously press the “

E1

”  and “

E3

”

buttons.

- Once the “BEEP” acoustic signal is heard, the “

E2

”

and

“

E3

”

displays with show the power level of the hob.

- Use  the  “

+

”

or

“

-

” buttons on the “

E2

”  and “

E3

” display, all

possible levels the hob can be set at will appear in sequence.

Code:

Maximum Power Watts

7 2

5200 W

2 8

2800 W

3 5

3500 W

6 0

5200 W

- Once the desired power level has been set, press the “

E1

”

and

“

E3

” buttons simultaneously, then disengage the key button

“

B

”.

- The cooktop is adjusted to the desired power.

- To change the power again, repeat the whole procedure.

Operation:

 every time one wants to increase the power level

of a zone, the system automatically calculates total power.
