9

POSITIONING

The domestic appliance was built in order to

be encased on a work surface, the way it is

illustrated in the graph (Fig.1). Predispose

sealing material (Fig.4) along the whole

perimeter (for dimensions of the cut see

Fig.1). Lock the domestic appliance into

place with 4 supporters, keeping in mind

the width of the surface (Fig.2).

If the lower part of the appliance after

installation, is accessible via the lower part

of the furniture, it is necessary to mount

a separating panel keeping in mind the

distances indicated (Fig.3). This is not

necessary if underneath the induction hob

is installed an oven.

VENTILATION

The distance between the cooktop and

built-in kitchen’s furniture or cooking

apparatuses  must  guarantee  sufficient

ventilation of the air. Not to use the cooktop

if in the oven is in course the pyrolysis

process.

ELECTRICAL CONNECTIONS

 (Fig.5)

Before making the electrical connections,

check that:

-

the system ratings meet the ratings

indicated  on  the  identification  plate  fixed

on the lower part of the worktop;

- the  system  is  fitted  with  efficient  ground

wires in accordance with the laws and

current standards.

Grounding is mandatory by law.

If the domestic appliance is not supplied

with a cable and/or suitable plug, use

material suitable for the absorption value

indicated on the identification plate and the

operating temperature.

If wishing to make a direct connection to

the mains, an omnipolar switch must be

installed with a minimum 3 mm opening

between the contacts and appropriate

for the load indicated on the plate and in

accordance with current standards (the

yellow/green ground conductor must not

be disconnected by a switch).

When the appliance has been installed, the

omnipolar switch must be easily reachable.

USE AND MAINTENANCE

The fundamental characteristic of the

induction system is the direct transference

of heat from the generator to the cooking

recipient.

Advantages:

- The transference of power takes place

only when the recipient is placed on the

cooking zone.

- The heat is generated only at the base

of the recipient and transferred directly to

the food to be cooked.

- Reduced  heating  time  and  low

consumption of power during the

beginning of cooking, allowing a global

saving of power.

- The fibreglass top remains cold, the heat

felt  on  the  cooking  top  is  that  reflected

from the base of the recipient.

COOKING RECIPIENTS

The use of appropriate recipients is an

essential factor for induction cooking.

Check that your pots are suitable for the

induction system.

The recipients must

contain iron.

 You can check whether

the material of the pot is magnetic with a

simple magnet (Fig.6).

We  advise  recipients  having  a  flat  base

(Fig.7A).  This way you can use the power

optimally.

Do not use recipients with a rough base

to avoid scratching the thermal surface of

the top.

A very important factor in induction cooking

is the dimension of the pot compared to

the plate used (Fig.7B).

The cooking zones allow the use of

recipients with bases of various diameters.

It is, however, preferable to use the

appropriate cooking zone for the dimension

of the pot.

COOKING ZONE

DIAMETER

MINIMUM PAN

DIAMETER

Ø 145 mm

80 mm

Ø 210 mm

130 mm
