EN - 15

be displayed and the hob will switch off.

Key Lock

The key lock function is used to set

‘safe mode’ on the appliance during

operation. It will not be possible to make

any adjustments by pressing the buttons

(for example heat settings). It will only be

possible to switch the appliance off.

The lock function is active if the key lock

button   is pressed for at least 2 seconds.

This operation is acknowledged by a

buzzer. After successful operation, the key

lock indicator will flash and the heater will

be locked.

Timer Function

The timer function is available in two

versions, as follow.

Minute Minder Timer (1 - 99 min.)

The minute minder timer can be operated

if the cooking zones are switched off. The

timer display will show “

00

” with a blinking

dot.

Use the Timer   and Sliding Button

 to increase/decrease the time.

The range is between 0 and 99 minutes.

If there is no adjustment to the displayed

time within 10 seconds, the minute minder

timer will be set and the blinking dot will

disappear. Once the timer is set, it begins to

count down.

When the timer reaches zero, a signal will

sound and the timer display will blink. The

sound signal will stop automatically after 2

minutes and/or by pressing any button.

The minute minder timer can be changed or

switched off any time by using the Timer

and Sliding Button

. Switching off

the hob by touching   at any time will also

switch off the minute minder timer.

Cooking Zone Timer (1 - 99 min.)

When the hob is switched on, an

independent timer can be programmed for

each cooking zone.

Select a cooking zone, then select the

temperature setting and, finally, activate the

timer setting button   , the timer can be

programmed to switch off a cooking zone.

Four LEDs are arranged around the timer

that indicate which cooking zone the timer

has been set for.

10 seconds after the last operation, the

timer display will change to the timer that

will run out next (in cases where a timer is

set for more than one cooking zone).

When the timer has run down, a signal will

sound, the timer display will show “

00

” and

the assigned cooking zone timer LED will

blink. The programmed cooking zone will

switch off and “

H

” will be displayed if the

cooking zone is hot.

The sound signal and the blinking of the

timer LED will stop automatically after 2

minutes and/or by pressing any button.

Buzzer

While the hob is in operation, the following

activities will be signalled by the buzzer.

•  Normal button activation will be

accompanied with a short sound signal.

•  Continuous button operation over a

longer period of time (10 seconds)

will be accompanied with a longer,

intermittent sound signal.

Boost Function

To use this function, select a cooking zone

and set the desired cooking level, then

press the “

P

” (Boost) button.

The Boost function can only be activated

if it is applicable with the cooking zone

selected. If the Boost Function is active,

a “

P

” will be shown on the corresponding

display.

Activating the booster can exceed the

maximum power, in which case the

integrated power management will be

activated.

The necessary power reduction is shown

by the corresponding cooking zone display

blinking. Blinking will be active for 3

seconds to allow for further adaptations of

the settings before power reduction.

Bridge Zone

Switching the Bridge Zone On

Touch the front left and rear left heater

selection buttons simultaneously. A static

dot will be shown on the left heater display.

The other displays will show ‘

b

’ and ‘

r

’, the

blinking dots will no longer be displayed.

Select the temperature setting by using the

sliding button. Increase the heat setting by

pressing the right side of the sliding button

or decrease the heat setting by pressing the

left side of the sliding button.

The bridge element will be ready to use.

For the fastest boil time, select the desired

cooking level, then press the “

P

” key to

activate the Boost function.

Switching the Bridge Zone off

To select the Bridge element, press the rear

left or front left heater selection button and,
