EN - 14

9-

 Sliding Buttons

10-

 Boost

11-

On/Off

Use the induction cooking zones with

suitable cookware.

After mains voltage is applied, all displays

are illuminated briefly. After this, the hob is

in stand-by mode and ready for operation.

The hob is controlled by pressing the

appropriate electronic button. Each button

pressed is followed by a buzzer sound.

Switching the Appliance On

Switch the hob on by pressing the ON/OFF

button   . All heater displays will show a

static “

0

” and the bottom right dots blink.

(If a cooking zone is not selected within 20

seconds, the hob will automatically switch

off).

Switching the Appliance Off

Switch the hob off at any time by pressing

.

The ON/OFF button   always has priority

over the switch-off function.

Switching the Cooking Zones On

Press the heater selection button that

corresponds to the heater you wish to use.

A static dot will be shown on the selected

heater display and the blinking dots on

all other heater displays will no longer

illuminate.

For the selected heater, you can set the

heat level by pressing the Sliding Button

 The element is now ready to

use. For fast boil times, select the desired

cooking level, then press the “

P

” button to

activate the Boost function.

Switching the Cooking Zones Off

Select the element you want to switch off

by pressing the heater selection key. Using

the Sliding Button

 , turn the

temperature down to “

0

”. (Pressing the right

and left of the slider button simultaneously

also turns the temperature to “

0

”).

If the cooking zone is hot, “

H

” will be

displayed instead of “

0

”.

Switching all Cooking Zones Off

To switch all the cooking zones off at once,

press the   key.

In stand-by mode, a “

H

” will appear on all

cooking zones which are hot.

Residual Heat Indicator

The residual heat indicator indicates that

the glass ceramic area has a temperature

that is dangerous to touch.

After switching off the cooking zone, the

respective display will show “

H

” until the

corresponding cooking zone temperature is

at a safe level.

Smart Pause

Smart Pause, when activated, reduces

the power of all burners that have been

switched on.

If you then deactivate the Smart Pause,

the heaters will automatically return to the

previous temperature level.

If the Smart Pause is not de-activated, the

cooktop will switch off after 30 minutes.

Press     to activate Smart Pause. The

power for the activated heater(s) will reduce

to level 1 and “

II

” will appear at all displays.

Press     again to deactivate Smart

Pause. “

II

” will disappear and the heaters

will now run at the level previously set.

Safety Switch-Off Function

A cooking zone will automatically switch off

if the heat setting has not been modified

for a specified duration of time. A change

in the heat setting of the cooking zone will

reset the time duration to the initial value.

This initial value depends on the selected

temperature level, as shown below.

Heat setting

Safety switch off after

1-2

6 Hours

3-4

5 Hours

5

4 Hours

6-9

1.5 Hours

Child Lock

After switching on the appliance, the child

lock function can be activated. To activate

the child lock, simultaneously press the

left and right side of the Sliding Button

 and then press the right side

of the Sliding Button

 again. “

L

”

indicating LOCKED will appear on all heater

displays and the controls can not be used.

(If a cooking zone is in the hot condition,

“

L

”and “

H

” will display alternately).

The hob will remain in a locked condition

until it is unlocked, even if the appliance

has been switched off and on.

To deactivate the child lock, first switch on

the hob. Simultaneously press the left and

right side of the Sliding Button

and then press the left side of the Sliding

Button

 again. “

L

” will no longer
