13

ENGLISH

SAFETY DEVICES ON THE COOKER

Safety shutdown

If a cooking area exceeds the maximum time for operation at the same power, it is auto-
matically switched of and the indication of the residual heat is shown.
To reset the cooking area, touch the necessary keys.

Power level

1

low

2

3

4

5

6

7

8

9

P

Maximum
duration of
operation in
hours

8.7 2.0

8.7 6.7 5.3 4.3 3.5 2.8 2.3 1.9 1.5

The cooker switches of automatically if one or more controls stay covered for more than
10 seconds.

To restore the proper operation:
- remove all objects from the control panel.
- clean the control panel.
- restart the cooker and the concerned area.

Overheating device

Before items of the cooker can overheat, the control reduces the used power by follow-
ing this procedure for protection measures:
- Deactivation of booster and power booster if turned on.
- Reduction of the power level set.
- Shutdown of the cooking area concerned.
On the display of the cooking area the message “E2” is displayed.

It is possible to restore the cooking area when the default message is of.

SAFETY INSTRUCTIONS
 FOR ASSEMBLY

Install the cooker after installing kitchen cabinets and basis.

Make sure that worktops have been veneered with thermoresistant glue in
order not to sufer delections or detachments.

It is forbidden to install the appliance on fridges or freezers, washing ma-
chines, dishwashers, or tumble driers.

ELECTRICAL SAFETY

The electrical system to which the cooker is to be connected must be in

accordance with local standards and supplied with earthed connection in
compliance with safety regulations in the country of use. It must also com-
ply with European standards regarding radio antistatic properties.

Make sure that it can’t be possible to touch the power cable of the cooker after it has been

built-in and that it is not subject to mechanical stress.

The  socket  used  to  connect  the  installed  equipment  to  the  electrical  power  supply  must
be within reach: otherwise, install a mains switch to disconnect the hood when required.

Any changes to the electrical system must be carried out by a qualiied electrician.

Do not try to solve the problem yourself in the event of equipment malfunction, but contact

the Dealer or an authorised Servicing Department for repairs.

When installing the cooker, disconnect the equipment by removing the
plug or switching of the main switch.

ELECTRICAL CONNECTION

(only intended for qualiied personnel)

Disconnect the equipment from mains power network before carrying out
any operation on the cooker.
Make sure that electric wires inside the cooker are not disconnected or cut:
in the event of damage, contact your nearest Servicing Department.

Refer to qualiied personnel for electrical connections.
Connection must be carried out in compliance with the provisions of law in force.

Before connecting the cooker to the mains power network, check that:
•  the  mains  voltage  corresponds  with  the  voltage  indicated  on  the  data  plate  located

inside the cooker;

•  the electrical system is compliant and can withstand the load (see the technical specii

-

cations located inside the cooker);

•  the power supply plug and cable do not come into contact with temperatures exceed

-

ing 70 °C;

•  the power supply system is efectively and properly connected to earth in compliance

with regulations in force.

•  the socket used to connect the cooker is within reach.

In case of:

•  devices itted with cables without a plug: the type of plug to use is a ЕЕstandardisedЕЕ one.

The wires must be connected as follows: yellow-green for earthing, blue for neutral and
brown for the phase. The plug must be connected to an adequate safety socket.

•  ixed equipment not provided with a power supply cable and plug, or any other device

that  ensures  disconnection  from  the  electrical  mains,  with  an  opening  gap  of  the  con

-

tacts that enables total disconnection in overvoltage category III conditions.

Said disconnection devices must be provided in the mains power supply in compliance
with installation regulations.

The yellow/green earth cable must not be cut of by the switch.
The Manufacturer declines all responsibility for failure to comply with the safety regulations.

Connection of the cooker:

network

Connection

Cable
section

Power
cable

Switch
gauge

230V~
50/60Hz

Single-phase
+ N

3 x 2.5
mm²

H 05 VV - F
H 05 RR - F

25 A *

* calculated with the contemporary factor in compliance with EN 60 335-2-6.

POWER:

Feature

38

38 Full Power

Total power

3500W

3500W

Front position

Rated power

1600W

2100W

Booster power

1850W

3500W

Back position

Rated power

2100W

2100W

Booster power (1/2)

2100/3000W

3500W
