10



Griddle cooking recommendations

FOOD KNOB

POSITION SETTING

Eggs

5-6

150°C to 160°C

Bacon; Breakfast Sausage

6

177°C to 190°C

Toasted Sandwiches

5-6

160°C to 177°C

Boneless Chicken Breasts

6

177°C to 190°C

Boneless Pork Chops, ½” thick

6

177°C to 190°C

Ham Slices, ½” thick

6

177°C to 190°C

Pancakes; French Toast

6

177°C to 190°C

Potatoes; Hash Browns

7

190°C to 205°C

USING THE CERAMIC INDUCTION ELEMENTS

Safety Precautions - Read before operating your cooktop

Your induction-cooking unit has been designed for residential use and food preparation, and all of the safety
parameters have been designed accordingly.
The unit incorporates numerous safety devices and controls, a few of which will be mentioned below:
- A number of sensors monitor the temperature of the internal components. If any of these sensors senses
that the component temperature is above the limit, the power output of the unit will automatically be reduced,
allowing the component to cool down. Once this is achieved, the unit will continue to operate normally at the
output level set initially by the operator..
-Each induction element is equipped with a sensor which is continuously monitoring the temperature of the
bottom of the pan to prevent the pan from overheating.

-Each induction element is equipped with a pan sensing device. This device will not allow the element to turn
on unless it senses an induction-compatible pot or pan on the element covering enough surface area.  If no
pot/pan is detected, the digital display will flash indicating that there is no power on the element. Once an
induction-compatible piece of cookware is sitting properly on the element, the digital display will become
steady, and the cookware will start heating up. Note that a small object as a fork, a spoon, a piece of jewelry,
etc. will not be mistaken for a cooking utensil, and it will not trigger this sensor. Moreover, this device will
distinguish between pots and pans which are and are not suitable for induction cooking.

If a piece of cookware, which is not suitable for induction cooking, is placed on an element, there will be no
power output on the element.
We reserve the right to make any changes to internal components, as well as, to make any (cosmetic)
modifications on the outside in an effort to improve our products.
Users with pacemakers or defibrilators must consult with their pacemaker manufacturer or their physician
prior to using this cooktop which incorporates an induction heating source.

If a crack appears in the glass surface, disconnect the unit immediately to avoid any risk of electric shock. If
the unit is connected directly to supply inside a junction box, then disconnect its breaker, or remove fuses
manually.
Do not use your cooktop until the glass top has been replaced.

When cooking, never use aluminum foil, never place products wrapped in aluminum foil or products deep-
frozen in aluminum packs on the cooktop.
Aluminum foil could melt and damage the vitroceramic glass beyond repair.

The Principle of Induction

When an induction element, also called: ‘a heating zone’ or simply: ‘a coil’ - is switched on, the appropriate
piece of cookware used, and a desired level of heating power selected, the electronic circuit unit (‘induction
generator’ or ‘inverter’) powers up the induction element which creates a magnetic field. This magnetic field
continuously changes in terms of frequency and intensity, and this creates induced ‘eddy’ currents in the
bottom of the pot or pan and ultimately results in heat. The heat is transferred directly to the  food being
cooked.
