Instructions for the installer

26

3

ELECTRICAL CONNECTION


  Make sure that the voltage and capacity of the power line conform to

the data shown on the plate located under the casing. Do not remove
this plate for any reason.


  The plug on the end of the supply cable and the wall socket must be

the same type and conform to the current electrical system regulations.
Check that the power line is adequately grounded.


  On the power line, install an omnipolar cut-off device with contact cut-

off distance greater than or equal to 3 mm, located in an easily
accessible position near the unit.


  Do not use reducers, adapters or shunts.


  If the power cable is replaced, the wire section on the new cable must

2

not be less than 1.0 mm

(3 x 1.0 cable), keeping in mind that the end

to

be connected to the hob must have the ground wire (yellow-green)
longer by at least 20 mm. Use only H05V2V2-F cable or similar which
has a maximum temperature of 90°C. Any replacement needed should
be carried out by a specialised technician who should make the mains
connections according to the following diagram.

L

 = brown

N

 = blue

= yellow-green

The manufacturer will not be liable for any damage to persons or
property caused by non-observance of the above instructions or

deriving from the tampering of even a single part of the hob.
