Technical passporT

english

english

Technical passporT

electric hob

electric hob

2. Place a suitable pan on the cooking zone that you wish

to use.

Â

Make sure the bottom of the pan and the surface of

the cooking zone are clean and dry.

3. Touching the heating zone selection control button

to select and active the cooking zone you wish to use.

The heat setting indicator of the selected zone will flash

when be active.

4. Then set heating level of cooking zone

1) touch control models:

Â

Set heat setting by touching the   or   button.

Â

If press and hold either of the two buttons, the

value will adjust down or up rapidly, from 0 to 9 in circle.

2) Slider touch control models:

Â

For the model with a touch slider control, you can

adjust heat setting by touching the slider control.

notes:

1. After connect to electricity, when power on, the buzzer of hob beeps once, all

indicators light up for 1 second then go out.

2. When the hob in Standby mode, if there is no practice within 1 minute, the

electric hob will auto turn off, with buzzer beeps once.

3.  To  turn  on  hob,  press  the  ON/OFF  control  button  and  hold  on  for  about  3

seconds; To turn it off, just need to press ON/OFF button again.

4. You can modify the heat setting at any time during cooking.
5. The default setting of power level is 5, and power level can be adjusted from 0

to 9. The heating element will turn off under power level 0, with indicator shows “-”

6.  The  heat  setting  indicator  of  the  selected  zone  will  flash  when  adjusting.

After adjusting, the number in indicator will flash for 5 seconds and then stop flash,
then the setting be confirmed.

to turn off hob

1. Touch heating zone selection control button, then turn

the cooking zone off by touching   or   control button

adjust heat setting to 0 level, which indicator shows“-“.

2. You can also turn the whole hob off by touching the

ON/OFF

 control button.

note:

The Timer/Minute Reminder setting will be canceled if hob be turn off.

note:

 If there is power cut off during cooking, all programmer setting will be

cancelled, you need to reset the programmer again.

note:

The cooling fan of induction hob will remain on for about 1 minute after

the hob be turned off.

Beware of hot surfaces

After turn off, the letter ”H”

 will show in the power setting indicator which

cooking zone is hot to touch. It will disappear when the surface has cooled down to

a safe temperature. It can also be used as an energy saving function if you want to

heat further pans, use the hotplate that is still hot.

When in Standby mode, if the surface of cooking zone is hot to touch, the letter

“H” and “-” will show in its heat setting indicator alternately.

U S i n G  L a rG e  H e at i n G a r e a-c e ra m i c  H O B

Some of ceramic hob models might have one or several extended cooking zones

(Oval/Dual/Triple zone), these extended zones can provide larger cooking area and

additional heat. To active the extended zone, please follows below:

1. Turn on the hob by touch ON/OFF

  control button.

2. Select the cooking zone which has extended zones, by

touch the heating zone selection button of it. Then adjust

the heat setting of it, the central zone will switch on.

3. Touch the extended zone control button

 to active

extended heating element to get a large heating area.

notes:

1. By continuous touch the control button, the extended

zone work at below consequence:

- Oval zone: “Central-Oval-Central-Oval-Central zone…”

- Dual zone: “Central-Dual-Central-Dual-Central zone…”

-  Triple  zone:  “Central-Dual-Triple-Central-Dual-Triple-

Central zone…”
