perimeter of the hob and insert it into the fitment hole (for

sizing see Fig.5B). Fix the appliance into the worktop with

the 4 stays, rotating them according to the top’s depth

(Fig.5A). If the underside of the appliance will be accessible

after installation, a separator panel

G

 (Fig.8A) will need to be

mounted maintaining the distances shown (Fig.8B). If the

appliance is installed over an oven the panel is not necessary

(Fig.9A - Fig.9B).

Important:

 if there is an oven under the induction hob it is

advisable for it to have a cooling fan. Do not use the induction

hob while

PYROLITIC

 cleaning is in process.

Warning:

 to allow the circulation of as much fresh air as

necessar y, there must be at least

 40 mm

between the

induction hob module and any appliance installed under it

(Fig.9B). In any event, adequate aeration must be provided.

To allow fresh air circulation there must be openings in the

kitchen furniture (Fig.8A - Fig.9A) of the sizes indicated in

Fig.8B - Fig.9B.

Electrical connections (Fig.2B):

Before making the electrical connections, check that:

- The ground cable is 2 cm longer than the other cables;

- The system ratings meet the ratings indicated on the

identification plate fixed on the lower part of the worktop;

- The system is fitted with efficient earthing compliant to the

laws and regulations in force.

If the appliance is not fitted with a cable, use type:

H05V2V2-F

” for a power level of up to 6400 Watts. The

cross-section of the cable should be at least 2.5 mm², or 4

mm² for greater power levels. The cable should never reach

a temperature which is 50°C above the temperature of the

room in which it is installed. The appliance is designed for

permanent connection to the electricity supply and should

therefore be fitted with an omnipolar switch which has a

minimum opening of 3 mm between contacts. The switch

should be suitable for the charge indicated on the appliance

data plate and must conform to all current legislation (the

yellow/green earth wire must not be interrupted by the

switch). The omnipolar switch must be easy to reach once

the installation process has been completed.

  USE AND MAINTENANCE

•  Use (Fig.2 - Fig.3):

A = ON/OFF

 button

B =



Pause/Recall

C =



ON/OFF Pause/Recall

Indicator

D1 =



Slider

Control

D2 =



Cooking level

indicator

E =



Cooking zone

selection



button

I =

 Residual heat symbol “

H

L1 =

 Quick



Heat



Function (

Heat up

ON/OFF

button

N =



Timer

Buttons

N1 =

 Tenths display

N2 =

 Units display

O =

 Hob indicator with

 timer

function active

Q =



Timerz

Display

R = Cooking zone

display

R1 =

 Active cooking zone indicator

S =

Booster

- To start the hob, press the button (

A

), on all displays (

R

) the

zeros will appear for 20 seconds with flashing decimal points.

If no operation is performed within this time period, the hob

switches off.

- It is possible to switch a

cooking



zone

 on by selecting one of

the 4 buttons (

E

). The cooking zone is active when the decimal

point becomes fixed.

Set the desired cooking level by acting on the

SLIDER



control (

D1

).

Note:

to set the cooking level, just slide your finger over

the

SLIDER



control

 (

D1

).

From

Left

 to

Right

 the temperature level is increased (

D2

from

 1



to



9

. To decrease just perform the operation in the

reverse order.

The cooking level (e.g.

6

) will appear on the cooking zone

display (

R

).

Note:

 you may also directly press any point on the

SLIDER



control without running your finger along it; in this case the

temperature level corresponding to the point at which the

control was touched will be activated directly.

- There are several different ways of switching off a

cooking

zone

:

1- Select it and run your finger over the

SLIDER

 control until

you  reach “

0

”.

2- Select it and directly press the “

-

” symbol on the

SLIDER



control.

- When  a

cooking  zone

(

E

) is switched to the

OFF

 setting

and the temperature of the glass surface remains above

approximately 50°, the display (

R

) corresponding to that zone

will show a luminous signal alternating between “

0

”  and “

H

”.

- If  the

hob

 is switched to the

OFF

 setting (

A

), the luminous

signal will display the letter “

H

” in a fixed manner.

Warning:

To prevent damage being inflicted on the electronic circuits,

the hob is fitted with an overheating safety system. In

situations where the appliance is used at high power levels for

a prolonged period of time, the hob may switchoff one or more

of the activated zones temporarily, until the temperatures

return to the set levels. On the display corresponding to the

cooking zone which has been temporarily switched off, the

power level will be shown in alternation with a

E/2

. This will

stop flashing once the cooking zone has beenreactivated.

•  Key function:

To keep children or persons needing supervision from using

the hob surface, all of the functions can be blocked in the

following way:

1- Switch to hob on (if it is off ) by selecting the “

ON/OFF

”

key. The cooking zones must be off.

2- Press  the “

S

” key and the R4 (Fig.2) or R3 (Fig.3) key

simultaneously according to the model you own.

3- Press only the cooking zone R4 (Fig.2) or R3 (Fig.3) key

once again according to the model you own.

The “

L

” letter indicating that the function is active will appear

on the display.

Should one or more zones still be hot, the letter “

H

”  and “

L

”

will alternate on the relative displays.

- To

deactivate the key function

, switch the hob off (if it

is on) by selecting the “

ON/OFF

” key.

- Once it is off, switch the hob back on.

- Press  the  “

S

” key and the R4 (Fig.2) or R3 (Fig.3) key

simultaneously according to the model you own.

- Press  the“

S

” key a second time.

- Zeros will appear on all the displays for a few seconds.

- If the cooker top is switched off with the KEY function active,

when subsequently activated the top will be in the same

situation, meaning with the KEY function active.

- If the hob is switched on and the

 Lock

function is enabled,

button

ON/OFF

 will still work.

- 30 -
