13 ENGLISH

Installing the guard

WARNING:

Never use the tool without the

guard illustrated in place.

 Failure to do so can

cause serious personal injury.

CAUTION:

Take care not to injure yourself on

the cutter for cutting the nylon cord.

►

Fig.16

1.

  Align the projections on the protector with the

grooves of the motor housing.

►

Fig.17:

1.

 Protector

2.

 Projection

3.

 Groove

2.

  Align the projections on the protector holder with

its counter parts of the motor housing.

►

Fig.18:

1.

 Protector holder

2.

 Projection

3.

  Tighten the hex bolts securely to fasten the protec

-

tor and the protector holder.

►

Fig.19:

1.

 Hex bolt

Installing the wire guard

CAUTION:

Before adjusting the wire guard,

wait for the cutting head comes to standstill. Do

not adjust the wire guard with your foot.

►

Fig.20

To reduce the risk damaging the objects in front of the

cutting head, insert the wire guard so that it controls the

cutting range of the mowing line.

Slightly expand the wire guard outward and then insert

it into the holes of the protector.

►

Fig.21:

1.

 Wire guard

NOTE:

 Do not expand the wire guard outward too

much. Otherwise it may break.

When wire guard is not in use, lift it for the idle position.

►

Fig.22

Installing nylon cutting head

Optional accessory

CAUTION:

If the nylon cutting head acciden-

tally impacts a rock or hard object during oper

-

ation, stop the tool and inspect for any damage.

If the nylon cutting head is damaged, replace it

immediately.

 Use of a damaged cutting tool could

result in serious personal injury.

CAUTION:

Make sure to remove the hex

wrench after installation.

NOTICE:

Be sure to use genuine Makita nylon

cutting head.

1.

Turn the tool upside down so that you can replace

the cutting tool easily.

2.

  Insert the hex wrench through the hole on the

motor housing and rotate the receive washer until it is

locked with the hex wrench.

3.

Place the nylon cutting head onto the threaded

spindle directly and tighten it by turning it clockwise.

4.

  Remove the hex wrench.

To remove the nylon cutting head, turn it counterclock-

wise while holding the receive washer with the hex

wrench.

►

Fig.23:

1.

 Nylon cutting head

2.

 Metal guard

3.

 Receive washer

4.

 Hex wrench

OPERATION

Correct handling of tool

WARNING:

Always position the tool on your

right-hand side.

 Correct positioning of the tool allows

for maximum control and will reduce the risk of seri

-

ous personal injury caused by kickback.

WARNING:

Be extremely careful to maintain

control of the tool at all times. Do not allow the

tool to be deflected toward you or anyone in the

work vicinity.

 Failure to keep control of the tool

could result in serious injury to the bystander and the

operator.

►

Fig.24

Attachment of shoulder harness

CAUTION:

Always use the shoulder harness

attached. Before operation, adjust the shoulder

harness according to the user size to prevent

fatigue.

Connect the clasp of the shoulder harness to the hook

part of the housing. Put the shoulder harness on. Be

sure that the buckles are locked completely in place.

►

Fig.25:

1.

 Buckle

2.

 Hook

Detachment

The buckle is provided with a means of quick release.

Simply squeeze the sides of the buckle to release the

tool.

►

Fig.26:

1.

 Buckle

MAINTENANCE

WARNING:

Always be sure that the tool is

switched off and battery cartridge is removed

before attempting to perform inspection or main-

tenance on the tool.

 Failure to switch off and remove

the battery cartridge may result in serious personal

injury from accidental start-up.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.
