Bosch ART 26 Li 0.600.878.L00 - Инструкция по эксплуатации - Страница 21

F016 L70 510 | (15.11.07)

Bosch Power Tools

20

 | English

Noise/Vibration Information

Measured values determined according to
2000 / 14 / EG (1.60 m height, 1.0 m clearance)
and EN 28 662.
Typically the A-weighted noise levels of the prod-
uct are: Sound pressure level 80 dB(A); Sound
power level 88 dB(A). Uncertainty K = 5 dB.

Wear hearing protection!

The hand-arm acceleration is typically below
2.5 m/s

2

.

Declaration of Conformity

We declare under our sole responsibility that this
product is in conformity with the following stand-
ards or standardization documents: EN 786,
EN 60 335 according to the provisions of the di-
rectives 89 / 336 / EWG, 98 / 37 / EG, 2000/14 / EC.
2000/14/EC: The guaranteed sound power level
LWA is lower than 94 dB (A). Conformity assess-
ment procedure according to Annex VI.
Notified body: SRL, Sudbury England
Notified body identifications number: 1088
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen

20.08.2007, Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen

For Your Safety

Switch off and remove battery from ma-
chine before adjusting or cleaning.

The blade continues to rotate for a few seconds
after the cordless trimmer is switched off.
Caution

–  do not touch the rotating blade.

Assembly

Battery Charging

Observe correct mains voltage:

The voltage of

the power source must agree with the voltage
specified on the nameplate of the unit. Equip-
ment marked with 230 V can also be connected
to 220 V or 240 V.
Use only the charging unit supplied. Only this
charging unit is matched to the lithium-ion bat-
tery used in the product.
The battery is equipped with temperature moni-
toring that allows charging only in the tempera-
ture range between 0  ° C and 45  ° C. In this man-
ner, a high battery service life is achieved.

Note:

The battery is supplied partially charged.

To ensure full capacity of the battery, completely
charge the battery in the battery charger before
using your power tool for the first time.
The lithium ion battery can be charged at any
time without reducing its service life. Interrupt-
ing the charging procedure does not damage the
battery.

Removing the Battery

Press the battery unlocking button and pull out
the battery

15

 toward the rear.

Charging Procedure

The charging procedure starts as soon as the
mains plug is plugged into the socket and the
battery is then inserted into the battery charger

14

.

Firstly, place the battery

15

 as shown in the fig-

ure onto the front of the battery charger (

n

) and

then press the battery

15

 down at the rear (

o

).

To remove the battery, proceed in reverse order.
Due to the intelligent charging method, the
charging condition of the battery is automatically
detected and the battery is charged with the op-
timum charging current, depending on battery
temperature and voltage.
This gives longer life to the battery and always
leaves it fully charged when kept in the charger
for storage.

Dr. Egbert Schneider
Senior Vice President
Engineering

Dr. Eckerhard Strötgen
Head of Product
Certification

A
