ENGLISH

(Original instructions)

Edging mode (fig. E, H & J)

For edging, the trimmer head should be in the position shown

in fig. J. If it is not:

u

  Disconnect the tool from the supply.

u

  Loosen the adjustment collar (15) by turning it clockwise.

u

  Whilst holding the handle (2), rotate the head (8) anti-

clockwise.

u

  Tighten the collar (15) by turning it anti-clockwise.

Note: The head will only rotate in one direction.

Switching on and off

u

  To switch the tool on, squeeze the trigger lever (1).

u

  To switch the tool off, release the trigger lever.

Warning! Never attempt to lock the trigger lever in the on

position.

Hints for optimum use

General

u

  In order to achieve optimum cutting results, only cut dry

grass.

Trimming

u

  Hold the tool as shown in fig. I.

u

  Gently swing the trimmer from side to side.

u

  When cutting long grass, work in stages from the top. Take

small cuts.

u

  Keep the tool away from hard objects and delicate plants.

u

  Cutting line will wear faster and require more feeding if

the cutting is done along pavements or other abrasive

surfaces or heavier weeds are being cut.

u

  If the tool starts running slowly, reduce the load.

Edging

Optimum cutting results are achieved on edges deeper than

50 mm.

u

  Do not use the tool to create edges. To create edges,

use an edging spade.

u

  Guide the tool on its wheel (9) or edge guide (10) as

shown in fig. J.

u

  To make a closer cut, slightly tilt the tool.

Fitting a new spool of cutting line (fig. K)

Replacement spools of cutting line are available from your

Black & Decker dealer (cat. no. A6481).

u

  Unplug the tool.

u

  Keep the tabs (17) depressed and remove the spool cover

(18) from the spool housing (7).

u

  Remove the empty spool (19) from the spool housing.

u

  Remove any dirt and grass from the spool cover and

housing.

u

  Take the new spool and push it onto the boss in the spool

housing. Rotate the spool slightly until it is seated.

u

  Unclip the end of the cutting line and guide the line into

the eyelet (20). The line should protrude approx. 11 cm

from the spool housing.

u

  Align the tabs (17) on the spool cover with the cut outs

(21) in the spool housing.

u

  Push the cover onto the spool housing until it snaps

securely into place.

Warning! If the cutting lines protrude beyond the trimming

blade (22), cut them off so that they just reach the blade.

Winding new line onto an empty spool (fig. L, M &

N)

You may wind new cutting line onto an empty spool.

Replacement packs of cutting line are available from your

Black & Decker dealer (cat. no. A6170 (25 m), A6171 (40 m)).

u

  Remove the empty spool from the tool as described

above.

u

  Remove any remaining cutting line from the spool.

u

  Feed 2 cm of cutting line into the hole (23) in the spool as

shown (fig. L).

u

  Bend the cutting line and anchor it in the L-shaped slot

(24).

u

  Wind the cutting line onto the spool in the direction of the

arrow. Make sure to wind the line on neatly and in layers.

Do not criss-cross (fig. N).

u

  When the wound cutting line reaches the recesses (25),

cut the line. Let the line protrude approx. 11 cm from the

spool and hold a finger on the line to keep it in place (fig.

M).

u

  Proceed as described above to fit the spool on the tool.

Warning! Only use the appropriate type of Black & Decker

cutting line.

Troubleshooting

If your tool seems not to operate properly, follow the instruc-

tions below. If this does not solve the problem, please contact

your local Black & Decker repair agent.
Warning! Before proceeding, unplug the tool.

Appliance runs slowly

u

  Check that the spool housing can rotate freely. Carefully

clean it if necessary.

u

  Check that the cutting line does not protrude more than

11 cm from the spool housing. If it does, cut it off so that it

just reaches the line trimming blade.

Automatic line feed does not work

u

  Keep the tabs depressed and remove the spool cover

from the housing.

u

  Pull the cutting line until it protrudes 11 cm from the hous-

ing. If insufficient cutting line is left on the spool, install a

new spool of cutting line as instructed above.

u

  Align the tabs on the spool cover with the cut outs in the

housing.

u

  Push the cover onto the housing until it snaps securely

into place.

u

  If the cutting line protrudes beyond the trimming blade, cut

it off so that it just reaches the blade.
