4

3. Taking a Blood Pressure Measurement using this

Instrument

4. Appearance of the Heart Arrhythmia Indicator for

early Detection

The symbol

AM

 indicates that pulse irregularities were detected

during the measurement. Therefore, the result may deviate from your

normal blood pressure – repeat the measurement. In most cases, this

is no cause for concern. We advise you to tell your doctor if the symbol

appears on a regular basis (e.g. several times a week with measure-

ments taken daily). Show your doctor the following explanation:

5. Traffic Light Indication in the Display

The bars on the left-hand edge of the traffic light display

BM

 show

you the range within which the indicated blood pressure value lies.

Depending on the height of the bar, the readout value is either

within the normal (green), borderline (yellow) or danger (red)

range. The classification corresponds to the 6 ranges in the Table

as defined by the WHO, as described in «Section 1.».

•

There is a break of 15 seconds between the measurements

(15 seconds is adequate according to «Blood Pressure Moni-

toring, 2001, 6:145-147» for oscillometric instruments). A count

down indicates the remaining time and a beep will sound

5 seconds before the 2nd and 3rd readings will begin.

•

The individual results are not displayed. Your blood pressure

will only be displayed after all 3 measurements are taken.

•

Do not remove the cuff between measurements.

•

If one of the individual measurements was questionable, a

fourth one is automatically taken.

Checklist for taking a reliable measurement

1. Avoid activity, eating or smoking immediately before the

measurement.

2. Sit down for at least 5 minutes before the measurement and

relax.

3. Always measure on the same arm (normally left).
4. Remove close-fitting garments from the upper arm. To avoid

constriction, shirt sleeves should not be rolled up - they do

not interfere with the cuff if they are laid flat.

5. Always ensure that the cuff is positioned correctly, as shown

in the pictures illustrated on the short instruction card.

•

Fit the cuff closely, but not too tight.

•

Make sure that the cuff is 2 cm (0.75 inch) above your

elbow with the tube on the inside of your arm.

•

Support your arm so it is relaxed.

•

Ensure that the cuff is at the same height as your heart.

6. Press the ON/OFF button

1

 to start the measurement.

7. The cuff will now pump up automatically. Relax, do not move

and do not tense your arm muscles until the measurement

result is displayed. Breathe normally and do not talk.

8. When the correct pressure is reached, the pumping stops

and the pressure falls gradually. If the required pressure was

not reached, the instrument will automatically pump some

more air into the cuff.

9. During the measurement, the heart symbol

AN

 flashes in the

display and a beep sounds every time a heartbeat is detected.

10. The result, comprising the systolic

AQ

 and the diastolic

AR

 blood

pressure and the pulse

AS

 is displayed and longer beep is heard.

Note also the explanations on further displays in this booklet.

11. When the measurement has finished, remove the cuff and

pack it into the instrument as shown in

Fig. II

.

12. Enter the result in the enclosed blood pressure pass and

switch off the instrument. (The monitor does switch off auto-

matically after approx. 1 min.).

H

You can stop the measurement at any time by pressing the

ON/OFF button (e.g. if you feel uneasy or an unpleasant

pressure sensation).

Information for the doctor on frequent appearance of the

Arrhythmia indicator

This instrument is an oscillometric blood pressure monitor that

also analyses pulse frequency during measurement. The instru-

ment is clinically tested.
The arrhythmia symbol is displayed after the measurement, if pulse

irregularities occur during measurement. If the symbol appears

more frequently (e.g. several times per week on measurements

performed daily) we recommend the patient to seek medical advice.
The instrument does not replace a cardiac examination, but

serves to detect pulse irregularities at an early stage.
