Instruction manual

WA-22H

13

En

• A loose cuff  or a sideways protruding air-pocket causes false measurement values.
• With repeated measurements, blood accumulates in the respective arm, which can lead to false results. Correctly executed blood-pressure measurements
should therefore fi rst be repeated after a 1 minute pause.

5.3. Fitting the cuff

a) Pass the end of the cuff  (with sewn-in rubber stopper) through the metal stirrup so that
a loop is formed. The Velcro closer must be facing outwards. (Ignore this step if the cuff  has
already been prepared.)

b) Push the cuff  over the left upper arm so that the tube points in the direction of the lower arm.

c) Lay the cuff  on the arm as illustrated. Make certain that the lower edge of the cuff  lies ap-
proximately 2 to 3 cm above the elbow and that the rubber tube leaves
the cuff  on the inner side of the arm. Important! The mark (ca. 3 cm long bar) must lie exactly
over the artery which runs down the inner side of the arm.

d) Tighten the free end of the cuff  and close the cuff   with the closer.

e) There must be no free space between the arm and the cuff  as this would infl uence the result.
Clothing must not restrict the arm. Any piece of clothing which
does (e.g. a pullover) must be taken off .

f ) Secure the cuff  with the Velcro closer in such a way that it lies comfortably and is not too tight.
Lay the arm on the table (palm upwards) so that the cuff  is at the same height as the heart.
Make sure that the tube is not kinked.

g) Remain seated quietly for two minutes before you begin the measurement.

Comment

If it is not possible to fi t the cuff  to the left arm, it can also be placed on the right one. However all measurements should be made using the same arm.
