Operation

13

13

Operation

USB operation

Background information

• This unit supports playback of video files

with 3GP, ASF, AVI, MKV, MPG, M2TS, MP4,
TS, VOB extension, with video codecs WMV
V9, H263, MPEG-4, MPEGII and audio codecs
PCM, WAV, MP3, DD(AC3).

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.

• USB file systems supported: NTFS, FAT16,

FAT32. 2.0 USB version is supported,
maximum capacity is 1 TB. Max. load: DC5V,
500 mA. For correct and satisfactory operation,
licensed USB devices of famous brands should
be used with this unit. Avoid using USB devices
of unknown brands. Playback of some file
formats cannot be supported.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

* User has direct access to less storage than

that,  as  the  operating  system  and  pre-installed

applications  already  occupy  some  of  that

memory.

SMART TV

General Information

• This unit supports the SMART TV feature.

For a detailed information about its operation
please refer to a separate leaflet included in
the documentation package.

Technical specifications

Operations of file playback

• Insert a USB into the USB jack. Select

USB source and press OK button. The screen
will show a USB playback window, in which
you can select Movie, Music, Photo and File
contents to play by pressing LEFT/RIGHT
cursor buttons and OK button.

• In the content menu, press cursor buttons

to select folder, press OK button on the RC
to enter it, then press cursor buttons to select
the file you want to watch or to listen to. When
highlighting the file, the file information will
appear and picture will be previewed (not
available for music files). Press PLAY and
PAUSE buttons on the RC to play the selected
file.

• While playback, press

 button to pause

or resume playback. Press   button to stop
playback.

• When playing video files you can press

/

buttons to fast reverse or forward. You can

press

/

buttons to select the desired files

manually in normal condition.

Basic specifications

CPU

ARM Cortex A9
Dual Core 1008 Mhz

Operating

system

Android 6.0

RAM

1.5 GB DDR3

Storage

8  GB*  (extendable

by  external  USB

storage devices)

Connections

WiFi

802.11 b/g/n

Ethernet

LAN RJ-45

USB

USB 2.0
