Operation

9

9

Operation

OSD operation

•

Auto Tuning:

press OK buttons to select

the country and tune type for channels to start
automatic search and saving of available ATV
channels. After the search is finished, the unit
will skip to searching DTV channels, Radio
channels and Data. During the ATV search,
press MENU button to skip to DTV, Radio and
Data search.

•

DTV Manual Tuning

: Press LEFT/RIGHT

cursor buttons to select channel number. Press
OK button to start searching. When the nearest
available channel is found, the search will
stop and the channel will be saved under the
selected number. Press MENU button to quit.

•

ATV Manual Tuning

:

Storage To: select channel number.
System: select corresponding sound system.
Current CH: search for next available

channel starting from current frequency.

Search: press LEFT/RIGHT buttons; the

unit will search for next available channel
downward or upward and save it under the
current number.

Fine-Tune: perform fine adjustment of the

current frequency.

•

Programme Edit

: this item allows

you to sort TV programs according to your
preferences. Enter the program edit menu:

Delete:  Select the channel you want to delete.

Press red button to delete the channel.

Move (not available for DTV channels with

LCN): Highlight the needed channel. Press
yellow button; select the position to put the
channel into. Press yellow button to confirm.

Favorite: Select the channel you want to edit.

If this channel is your favorite channel, you can
add it to your favorite channel list by pressing
the FAV button.

Skip:  Highlight the needed channel. Press

blue button; now this channel will be skipped
when you select previous/next channels.

Edit: Select the needed channel. Press the

green button; now you can rename this
channel. Enter a new name and press OK to
confirm.

Channel setting

CHANNEL

Antenna Type
Auto Tuning
DTV Manual Tuning
ATV Manual Tuning
LNB Setting
Programme Edit

Hide Scrambled

Signal Information
CI Information

•

LNB Setting

:  configure the

settings of satellite.
    Satellites List: press UP/DOWN cursor
buttons to select a satellite whose settings will
appear on the right.

LNB Power: press LEFT/RIGHT cursor

buttons to adjust the power of the low-noise
block downconverter (LNB).

22K: press LEFT/RIGHT cursor buttons to

switch on or off the 22 kHz tone signal
reception, which is set at Auto when LNB Type
is a dual local oscillator.

1. Press MENU button to enter the setting

menu displayed on the screen.

2. Press LEFT/RIGHT cursor buttons on the

RC or on the keyboard to go to the needed
setting page. Press OK on the RC or press the
rocker button to confirm.

3. Press UP/DOWN cursor buttons on the

RC or on the keyboard to select a parameter to
adjust.

4. Press LEFT/RIGHT buttons on the RC or on

the keyboard to adjust the selected parameter.

5. Press MENU button to return to the root

menu or exit menu setting.
        Some menu items may be in gray color,
in this case they are not adjustable. Pictures of
OSD menu are for reference only; they may
differ from the real screens.

•

Hide Scrambled

:

remove scrambled

(pay-per-view) channels from the
channel list.
